Sonnet Morpheus - Specifications

Sonnet MORPHEUS
Specifications
Fully balanced Non oversampling DAC
Two SDA-2 dac modules per channel in differential mode
Power supply 15VA 110/115V AC 220/230V AC 60/50Hz. Power consumption max. 8 Watts.
Input 1x optical, 1x coaxial and 1x AES/EBU and USB
Output 1x stereo pair single ended 2 Volts RMS
Output 1x stereo pair XLR balanced 4 Volts RMS
Frequency Response 44.1 kHz sampling 1Hz – 20 kHz -2.5 dB
Frequency Response 192 kHz sampling 1Hz – 65 kHz – 3dB and 384kHz (USB)
Distortion 0.004% THD
Noise Floor -155 dB related to 2 Volt RMS
Output impedance RCA 100 Ohm, XLR 100 Ohm
Sampling rate Optical 44.1 – 96 kHz
Sampling rate Coax and AES/EBU: 44.1 -192 kHz
Sampling rate USB 44.1 – 384kHz
Aluminum six button remote control included.
MQAor the I2S option is available as an option. (I2S option can be installed instead of the USB module)
Dimensions 290 x 250 x 60 mm
Weight 3.2KG
