Sonoff SNZB-01 User Manual

>
CR2450
3V
3. Add sub-devices
Connect the Bridge before adding the sub-device
Access eWeLink APP, select the Bridge that you want to connect,
and tap “Add” to add a sub-device. Then long press “RST” reset
button on the device for 5s until the LED indicator flashes three
times, which means the device has entered the pairing mode, and
be patient until pairing completes.
ZBB ridge
Add ed:0
No c hild d evice ,plea se add .
Add
If the addition failed, move the sub-device closer to the Bridge and try again.
Specifications
Model
Battery model
Working voltage
Wireless connection
Working temperature
Working humidity
Material
Dimension
SNZB-01
CR2450
3V
ZigBee (IEEE 802.15.4)
-10~40℃
10-90%RH (non-condensing)
PC
43x43x16mm

Sonoff SNZB-01 Specifications

General

Model	SNZB-01
Type	Wireless Switch
Wireless Protocol	Zigbee
Battery	CR2032
Operating Temperature	-10°C to 40°C
Dimensions	43mm x 43mm x 16mm
