Sonoscape Flagship S9 User Manual

Annotation
1. Press [Annot] to choose the desired annotation through
touch screen, or input annotation through keyboard.
2. Press [Set] to locate the annotation position.
Body Mark
1. Press [Body Mark] and choose the desired one.
2. Move [Trackball] to place the probe marker, and rotate the
[Angle] to adjust the orientation of the probe.
Save Images or Cine
Press the [Save Frame] or [Save Cine] to save a single frame
image or cine into the system.
Review Patient File
Press [File] to the patient file which you are scanning, then
select a certain exam to review images and cines.
PW/CW Mode
1. Press [PW] to enter PW mode;
2. Move [Trackball] to change the position of sample volume;
3. Use [Set] to change the size of sample volume, and use
[Angle] to change the angle of sample volume line;
4. Press [Update] to activate the Pulse Wave Doppler image;
5. Press [M-tuning] to optimize the spectral Doppler;
6. CW is only available for phased array, and press CW on
the touch screen to enter CW mode.
3D/ 4D
1. Select the volume probe and choose the exam mode. Press
[3D/4D] on the touch screen under B mode;
2. Adjust the ROI and curve line by [Set] and [Update];
3. Press [Start] on the touch screen to enter the 4D image
real-time status.
Steer M mode (Anatomical M mode)
1. Under M mode, click [Steer M] on the touch screen to
enter;
2. Press left or right of [Steer M] to set the number of the
sample line, and rotate [Angle] to change the angle of the
sample line.
Tissue Doppler Imaging (only available for Phased
Array)
1. Under B mode, click [TDI] on the touch screen to enter TDI
mode;
2. Use [Trackball] and [Set] to change the position and size of
the ROI;
3. Press [PW] button to enter TVD mode;
4. Press [Update] to activate the Pulse Wave Doppler image.
3. Measurement
1. Calculation is active both in scanning mode and frozen mode;
2. Press [Distance] to calculate the distance;
3. Press [Area] to calculate the area and circumference;
4. Press [Calc] to enter the application measurement status.
5. Choose the desired measurement item, and mark on the right
position.
4. Post Scanning
5. Image Management
Image Transfer (only after you END the examination)
1. Press [Patient] on the touch screen, then enter the [Patient List]
to choose the images of a certain patient.
2. Choose the type of medium to USB. Then choose the type of file
you want to export, like JPG/BMP/AVI/MP4, etc;
3. Click [Export] to send the images to USB.
Note: For detailed information, please refer to the Operation
Manual.
6. Touch Screen Setting
Report and Print
1. Press [Insert Image] to add images, and then Press [Report],
input the comment in the text box.
2. Click [Print] on the report interface to preview the PDF report,
then press [Print] on the touch screen to print the report out.
End Exam
Press [End Exam] to end one examination.
Start a New Patient
You may start a new exam by repeating the instructions above.
Change Skin/Color Lightness/Audio
1. Press [Keyboard] on the touch screen and press [Set Up] to
enter into the touch screen setting;
2. Choose 3 different types of Skin:
[Royal Blue], [Snowy White], [Gray Black]
3. Choose 2 different parts of color lightness: [Touch Screen],
[Master]
4. Choose the [Volume] on the Touch Screen.
SonoScape International Marketing Dept.
Based on Software Version: 3.0.5.1
Elastography
Available in the breast and thyroid exam mode for all linear
probes;
Contrast Imaging
Available for C353

Sonoscape Flagship S9 Specifications

General

Brand	Sonoscape
Model	Flagship S9
Category	Medical Equipment
Language	English
