Scanning
Imaging modes
To switch from 2D to M Mode, press and hold 2D; press and hold M to return
to 2D.
 2D (default) – This mode displays echoes in two dimensions by assigning a
brightness level based on the echo signal amplitude.
 M Mode (Motion Mode) – This mode provides a trace of the image displayed
over time. A single beam of ultrasound is transmitted, and reflected signals
are displayed as dots of varying intensities, which create lines across the
screen.
 Color – This mode is used to visualize the presence, velocity, and direction of
blood flow in a wide range of flow states. To go to Color mode, tap Color on
the wheel while in 2D.
Performing a basic scan
In SonoSite iViz, the active imaging mode is always highlighted in blue so you
can tell what imaging mode you are using. For example, in Color mode, both
the 2D and Color buttons are highlighted in blue.
Adjusting gain and depth
 To adjust gain, on the control wheel, tap Overall Gain or Near/Far Gain, and
move the blue dot up and down the slider.
 To adjust depth, on the control wheel, tap Depth, and use the plus/minus
buttons to increase/decrease scan depth (or tap one of the dots for specific
screen-depth index).
Freezing and scrolling frames (cine)
1 While scanning, tap FREEZE.
2 View frames by dragging the green slider up and down to scroll through the
frames, or select the back arrow to return to the first frame or the forward
arrow to go to the last frame.
Scanning
Adding labels
1 Do one of the following:
a On a frozen image, tap Text Labels.
b On a saved image, open the bottom tool drawer by swiping upward on
the tool drawer handle in the lower right of the screen, then tap Tex t
Labels.
2 To add an arrow:
a Tap +Arrow.
b Using your finger, drag the arrow to a location on the screen.
c Using your finger, drag the blue orientation arrows to rotate the center
black arrow.
3 To add a standard label:
a Tap the label you want to add, such as Right or Medial.
b Using your finger, drag the label to a location on the screen.
4 To add a custom label to this image:
a Tap the text box at the top of the list of labels.
b Type the text of the label, and then tap Done.
c Using your finger, drag the label to a location on the screen.
Refer to the iViz User Guide for more information about creating and saving
Custom Labels.
