5. ELECTRICAL DESCRIPTION
32
LZ T 123 7605 P1C
Audio signal descriptions are listed below:
MICP and MICN are balanced differential microphone input signals.
These inputs are compatible with an electret microphone.
BEARP and BEARN are the speaker output signals. These are
differential-mode outputs. The electrical characteristics are given in the
table below.
The following table shows the ear piece impedances that can be connected
to BEARP and BEARN.
Pin Signal Dir Description
1 MICN I Microphone negative input
2 BEARN O Earpiece negative output
3 BEARP O Earpiece positive output
4 MICP I Microphone positive input
Parameter Limit
Output level (differential) 4.0V
pp
Output level (dynamic load = 32) 2.8V
pp
Distortion at 1kHz and maximum output level 5%
Offset, BEARP to BEARN ±30mV
Ear piece mute switch attenuation 40dB
Ear piece model Impedance Tolerance
Dynamic ear piece [32 + 800µH] // 100pF ±20%
Dynamic ear piece [150 + 800µH] // 100pF ±20%
Piezo ear piece 1k + 60nF ±20%
