Specifications
Camera
[System]
Camera Type:
Interchangeable Lens Digital Camera
Lens: Sony E-mount lens
[Image sensor]
Image format: 35mm full frame (35.7 mm ×
23.8 mm), CMOS image sensor
Effective pixel number of camera:
Approx. 61 000 000 pixels
Total pixel number of camera:
Approx. 62 500 000 pixels
[Electronic Viewfinder]
Type: 1.6 cm (0.64 type)
Electronic Viewfinder
[Monitor]
8.0 cm (3.2 type) TFT drive, touch panel
[General]
Rated input: 7.2V
, 4.5W
Operating temperature:
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature:
–20 °C to 55 °C (–4 °F to 131 °F)
Dimensions (W/H/D) (Approx.):
131.3 × 96.9 × 82.4mm
131.3 × 96.9 × 72.3mm
(from grip to monitor)
51/4 × 37/8 × 31/4in.
51/4 × 37/8 × 27/8in.
(from grip to monitor)
Mass (Approx.):
723g (1lb 9.6oz) (including battery
pack, SD Card)
[Wireless LAN]
WW282174 (see name plate on the bottom
of camera)
Supported format: IEEE802.11a/b/g/n/ac
Frequency band: 2.4GHz/5GHz
Security: WEP/WPA-PSK/WPA2-PSK
Connection method:
Wi-Fi Protected Setup™ (WPS)/Manual
Access method: Infrastructure mode
WW529928 (see name plate on the bottom
of camera)
Supported format: IEEE 802.11 b/g/n
Frequency band: 2.4 GHz
Security: WEP/WPA-PSK/WPA2-PSK
Connection method:
Wi-Fi Protected Setup™ (WPS)/Manual
Access method: Infrastructure mode
[Eco and energy saving]
Power consumption (Off mode): Not
available
Power consumption (Standby mode/Low
power mode): 0.5W
Power consumption (Networked standby
mode): 2.0W (Bluetooth) / 2.0W (all
terminals and networks connected)
Low power mode activated:
Within 20minutes (default)
Networked standby mode activated:
Within 20minutes (default)
Battery charger BC-QZ1/BC-QZ1 T
Rated input:
100 - 240V
, 50/60Hz, 0.38A
Rated output: 8.4V , 1.6A
Rechargeable battery pack
NP-FZ100
Rated voltage: 7.2V
Recommended USB-PD-compatible
AC adaptor
Input: 100-240V , 50/60Hz
Output:9V / 2A or more,
15V
/ 2A or more
Design and specifications are subject to
change without notice.
Trademarks
• is a trademark of Sony Group Corporation.
• USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum.
• Wi-Fi, the Wi-Fi logo and Wi-Fi Protected Setup are registered trademarks or trademarks of the
Wi-Fi Alliance.
• The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by Sony Group Corporation and its subsidiaries is under license.
• QR Code is a trademark of Denso Wave Inc.
• In addition, system and product names used in this manual are, in general, trademarks or
registered trademarks of their respective developers or manufacturers. However, the ™ or 
marks may not be used in all cases in this manual.
Notes on recording for long periods of time or recording 4K/8K movies
• The camera body and battery may become warm with use – this is normal.
• If the same part of your skin touches the camera for a long period of time while using the
camera, even if the camera does not feel hot to you, it may cause symptoms of a low-
temperature burn such as redness or blistering. Pay special attention in the following situations
and use a tripod, etc.
- When using the camera in a high temperature environment
- When someone with poor circulation or impaired skin sensation uses the camera
- When using the camera with [Auto Power OFF Temp.] set to [High]
Notes on using memory cards
• When recording is finished, the memory card may become hot. This is not a malfunction.
• If (overheating warning icon) is displayed on the monitor, do not remove the memory card
from the camera right away. Instead, wait for a while after turning off the camera, and then
remove the memory card. If you touch the memory card while it is hot, you may drop it and the
memory card may be damaged. Be careful when removing the memory card.
Notes on using a tripod
Use a tripod with a screw less than 5.5mm (7/32 inches) long. Otherwise, you cannot firmly
secure the camera, and damage to the camera may occur.
Sony lenses/accessories
Using this unit with products from other manufacturers may affect its performance, leading to
accidents or malfunction.
Warning on copyrights
Television programs, films, videotapes, and other materials may be copyrighted. Unauthorized
recording of such materials may be contrary to the provisions of the copyright laws.
Notes on location information
If you upload and share still images or movies taken with this camera on the
Internet while the location information is linked with the dedicated smartphone
application, you may accidentally reveal the location information to a third party.
To prevent third parties from obtaining your location information, deactivate the
[Location Information Linkage] function of the dedicated application.
Notes on discarding or transferring this product to others
Before discarding or transferring this product to others, be sure to perform the following
operation to protect private information.
• Select [Setting Reset]  [Initialize].
Notes on discarding or transferring a memory card to others
Executing [Format] or [Delete] on the camera or a computer may not completely delete the data
on the memory card. Before transferring a memory card to others, we recommend that you
delete the data completely using data deletion software. When discarding a memory card, we
recommend that you physically destroy it.
Note on network functions
When you use network functions, unintended third parties on the network may access the
camera, depending on the usage environment. For example, unauthorized access to the camera
may occur in network environments to which another network device is connected or can
connect without permission. Sony bears no responsibility for any loss or damage caused by
connecting to such network environments.
Note on the 5GHz band for wireless LAN
When using the wireless LAN function outdoors, set the band to 2.4GHz by following the
procedure below. (WW282174 only)
• MENU  (Network)  [Wi-Fi]  [Wi-Fi Frequency Band]
How to turn off wireless network functions (Wi-Fi, etc.) temporarily
When you board an airplane, etc., you can turn off all wireless network functions temporarily
using [Airplane Mode].
How to turn on or off Wi-Fi function
Select MENU  (Network)  [Wi-Fi]  [Wi-Fi Connect]  [On] or [Off].
How to turn on or off Bluetooth function
Select MENU  (Network)  [Bluetooth]  [Bluetooth Function]  [On] or [Off].
Power Cord
Multiple power cords may be supplied with this
equipment. Use the appropriate one that matches
your country/region.
For the customers in the UK, Ireland, Malta, Cyprus
and Saudi Arabia
Use the power cord (A).
For safety reasons, the power cord (B) is not intended
for above countries/regions and shall therefore not
be used there.
For the customers in other EU countries/regions
Use the power cord (B).
(A) (B)
For Customers in the U.S.A. and Canada
The available scientific evidence does not show that any health problems are associated with
using low power wireless devices. There is no proof, however, that these low power wireless
devices are absolutely safe. Low power Wireless devices emit low levels of radio frequency
energy (RF) in the microwave range while being used. Whereas high levels of RF can produce
health effects (by heating tissue), exposure of low-level RF that does not produce heating effects
causes no known adverse health effects. Many studies of low-level RF exposures have not found
any biological effects. Some studies have suggested that some biological effects might occur,
but such findings have not been confirmed by additional research. This equipment has been
tested and found to comply with FCC/ISED radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the
ISED radio frequency (RF) Exposure rules.
For Customers in the U.S.A.
For question regarding your product or for the Sony Service Center nearest you, call 1-800-222-
SONY (7669) .
Supplier’s Declaration of Conformity
Trade Name : SONY
Model : WW282174
Responsible Party : Sony Electronics Inc.
Address : 16535 Via Esprillo, San Diego, CA 92127 U.S.A.
Telephone Number : 858-942-2230
Important note on use of 5 GHz wireless LAN
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the MAC,
through the digital and analog baseband, and finally to the RF chip. Several special packets are
initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF
transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on
only while one of the aforementioned packets is being transmitted. In other words, this device
automatically discontinue transmission in case of either absence of information to transmit or
operational failure.
Frequency Tolerance: ±20 ppm
For Customers in Canada
5150-5350 MHz band is restricted to indoor operation only.
High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-
5350MHz and 5650-5850MHz and that these radars could cause interference and/or damage
to LE-LAN devices.
For Customers in Europe
IEEE802.11b/g/n 2 400 MHz < 60 mW e.i.r.p.
IEEE802.11a/n/ac 5 150-5 350 MHz
5 470-5 725 MHz
< 35 mW e.i.r.p.
IEEE802.11a/n/ac 5 725-5 850 MHz < 25 mW e.i.r.p.
Bluetooth 2 400 MHz < 10 mW e.i.r.p.
Hereby, Sony Corporation declares that this equipment is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https://www.compliance.sony.eu
Hereby, Sony Corporation declares that this equipment is in compliance with the UK relevant
statutory requirements.
The full text of the declaration of conformity is available at the following internet address:
https://compliance.sony.co.uk
For this radio equipment the following restrictions on putting into service or of requirements for
authorization of use apply in AT/BE/BG/CY/CZ/DK/EE/FI/FR/DE/EL/HU/IE/IT/LV/LT/LU/MT/NL/
PL/PT/RO/SK/SI/ES/SE/UK/UK(NI)/HR/IS/LI/NO/CH/AL/BA/MK/MD/RS/ME/XK/TR:
5150 - 5350MHz band is restricted to indoor operations only.
The power delivered by the charger must be between min 2.5 Watts required by the radio
equipment, and max 27 Watts in order to achieve the maximum charging speed.
USB PD fast charging
Deactivating the power management function will increase the energy consumption of the
product.
For Customers in the UK
STATEMENT OF COMPLIANCE
1. Model No.: ILCE-7RM5
2. Name and address of the manufacturer’s authorised representative: Sony Europe B.V., The
Heights, Brooklands, Weybridge, Surrey KT13 0XW, United Kingdom
3. This statement of compliance is issued under the sole responsibility of the manufacturer: Sony
Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan
4. Object of the statement: Interchangeable Lens Digital Camera
5. The object of the statement described above is in compliance with the applicable security
requirements in Schedule 1 of S.I. 2023 No. 1007 (Product Security)
6. Where applicable, references to the relevant standards used in relation to which compliance
is declared:
7. Defined support period for security updates: 2025-12-31
8. Additional information: Note(s):
Signed for and on behalf of:
Sony Europe B.V.
Kris De Pauw
Vice President
Weybridge, 2024-03-18
Sony Europe B.V.
Registered Office: The Heights, Brooklands, Weybridge, Surrey, KT13 0XW, United Kingdom ·
Incorporated in the Netherlands No. 71682147
The support period for security updates can be found on the page linked below. The date given
in this document is as of the time of release.
https://compliance.sony.co.uk
For Customers in Indonesia
IEEE802.11b/g/n 2 400 MHz
Bluetooth 2 400 MHz
For customers who purchased their camera from a store in
Japan that caters to tourists
Note
Some certification marks for standards supported by the camera can be confirmed on the screen
of the camera.
Select MENU 
(Setup)  [Setup Option]  [Certification Logo].
Additional information on this product and answers to frequently asked questions can be
found at our Customer Support Website.
