To Charge the Battery Pack see illustration a
The AC-V30 charges a battery pack NP-55 in about
one hour, and NP-77 in about two hours.
1 Connect the power cord to a wall outlet.
2 Install the battery pack.
Align the jjb marks, then while pressing the battery
pack, slide the battery pack in the direction of the
arrow.
The POWER lamp (green) and the CHARGE lamp
(orange) will light up. The charging will begin.
When the charging is completed, the CHARGE lamp
goes out. Unplug the unit from the wall outlet and the
POWER lamp will gose out.
6
When the CHARGE Lamp Flaches
Check through the following chart.
Remove the battery pack from the AC power
adapter.
* y° u use 3 battery which you have just bought
or which has been left unused for a long time, the
CHARGE lamp may flash at the first charging.’
But this is not a problem. Continue to charge with
the same battery.
