Sony BDV-E870 - Rear Panel Connections

12
US
A (USB) port (page 33)
B LAN (100) terminal (page 27)
C COMPONENT VIDEO OUT jacks (page
23)
D VIDEO OUT jack (page 23)
E HDMI OUT jack (page 23)
F EZW-T100 slot (page 42)
G AUDIO (AUDIO IN L/R) jacks (page 25)
H A.CAL MIC jack (pages 28, 49)
I ANTENNA (FM COAXIAL 75Ω) jack
(page 26)
J TV (DIGITAL IN OPTICAL) jack (page
24)
K SAT/CABLE (DIGITAL IN COAXIAL)
jack (page 25)
L SPEAKERS jacks (page 22)
* CAUTION
Please do not remove the screws unless you
are installing the EZW-T100.
Rear panel
FRONT R
SPEAKERS
FRONT L SUBWOOFER CENTER
SPEAKERS
SUR R SUR L
LAN 100)
COMPONENT VIDEO OUT
VIDEO OUT
Y P B / C B PR / CR
AUDIO
AUD O INRL
A CAL M C
ECM AC2
DIGITAL N
CO XIAL
SAT/CABLE
DIGITAL IN
TV
OP ICAL
OUT
ARC
EZW T100
COAX AL
AN ENNA
FM 75
Screws*
