HDCU-4300
(1)
INTERCOM/ TALLY/ PGM
(2)
RCP/CNU Remote
(3)
TRUNK
Optional Slot:
HKCU-IP43F (NMI) or
HKCU-4001 (ST2110) or
HKCU-4002 (12G SDI)
(A) LEMO SMPTE Connector
(1.1) Optional for HDCU-4300 (optional board CN-3847) / 50-pin Sub-D:
INTERCOM/TALLY/PGM/ MIC- REMOTE/WFREMOTE/ASPECT CONTROL/GPIO
