HDCU-3100
(2)
RCP Remote Connector
(A) LEMO SMPTE Connector
(1.1.)
INTERCOM/ TALLY/ PGM
/ MIC Remote/ WFM-
Remote
(3)
TRUNK
Optional Slot:
HKCU-SFP30 (ST2110) or
HKCU-SDI30 (12G SDI)
Optional Slot:
HKCU-SMF30 (Single Mode Fiber)
