XR-48A90K / 42A90K
5-039-048-11(1)
7
GB
HDMI IN 1/2/3/4 (HDCP 2.3-compatible)
Video:
4096 × 2160p (50, 60 Hz)*
1
*
2
, 4096 × 2160p
(24 Hz)*
1
, 3840 × 2160p (50, 60 Hz)*
2
, 3840 ×
2160p (24, 25, 30 Hz), 1080p (30, 50, 60, 100,
120 Hz), 1080/24p, 1080i (50, 60 Hz), 720p
(30, 50, 60 Hz), 720/24p, 576p, 480p, PC
Formats*
3
3840 × 2160p (100, 120 Hz)*
2
*
4
Audio:
In eARC (Enhanced Audio Return Channel)
mode
Refer to the online Help Guide for details.
Except eARC mode
5.1 channel linear PCM: 32/44.1/48/88.2/
96/176.4/192 kHz 16/20/24 bits, Dolby
Audio, Dolby Atmos, DTS
eARC/ARC (Enhanced Audio Return Channel/
Audio Return Channel) (HDMI IN 3 only)*
5
In eARC mode
Refer to the online Help Guide for details.
In ARC mode
Two channel linear PCM: 48 kHz 16 bits,
Dolby Audio, Dolby Atmos, DTS
DIGITAL AUDIO OUT (OPTICAL)
Digital optical jack (Two channel linear PCM:
48 kHz 16 bits, Dolby Audio, DTS)
(Stereo mini jack)
Headphone
1, 2
USB port 1 supports High Speed USB (USB 2.0)
USB port 2 supports Super Speed USB (USB 3.2
Gen 1)
LAN
10BASE-T/100BASE-TX connector (Depending
on the operating environment of the network,
connection speed may differ. The
communication rate and quality are not
guaranteed.)
Power and others
Power requirements
220V – 240V AC, 50Hz
Screen size (measured diagonally) (Approx.)
XR-48A90K: 48 inches / 120.7 cm
XR-42A90K: 42 inches / 105.5 cm
Power consumption
Indicated on the rear of the TV
Standby power consumption*
6
*
7
0.5 W
Display resolution (horizontal × vertical) (pixels)
3840 × 2160
Output rating
500 mA (for USB 1), 900 mA (for USB 2)
Dimensions (Approx.) (w × h × d) (mm)
with Table-Top Stand
Standard position:
XR-48A90K: 1069 × 629 × 225
XR-42A90K: 933 × 551 × 225
Soundbar position:
XR-48A90K: 1069 × 697 × 225
XR-42A90K: 933 × 620 × 225
without Table-Top Stand
XR-48A90K: 1069 × 624 × 59
XR-42A90K: 933 × 546 × 57
Stand width (Approx.) (mm)
500
Mass (Approx.) (kg)
with Table-Top Stand
Standard position:
XR-48A90K: 16.5
XR-42A90K: 16.4
Soundbar position:
XR-48A90K: 16.8
XR-42A90K: 16.7
without Table-Top Stand
XR-48A90K: 13.4
XR-42A90K: 13.3
Others
Optional accessories
Wall-Mount Bracket: SU-WL850 (XR-48A90K
only)
Wall-Mount Bracket: SU-WL450
Camera and Microphone Unit: CMU-BC1
Operating temperature: 0 ºC – 40 ºC
Operating humidity: 10 % – 80 % RH
(non-condensing)
*1 When 4096 × 2160p is input and [Wide mode] is set
to [Normal], the resolution is displayed as 3840 ×
2160p. To display 4096 × 2160p, set [Wide mode]
setting to [Full 1] or [Full 2].
*2 Refer to the on screen menu to set [HDMI signal
format].
*3 Refer to the online Help Guide for details.
*4 HDMI IN 3 & 4 only. Use the Ultra High Speed HDMI
Cable to connect.
*5 Connect your audio system to the HDMI IN 3 to route
TV audio to your audio system.
*6 Specified standby power is reached after the TV
finishes necessary internal processes.
*7 Standby power consumption will increase when
your TV is connected to the network.
Note
• Optional accessories availability depends on
countries/region/TV model/stock.
• Design and specifications are subject to change
without notice.
• Subscriptions for services and applications may be
required and additional terms, conditions and/or
charges may apply when using Google Assistant.
