REF NO. PART NO. DESCRIPTION REMARK
REF NO. PART NO. DESCRIPTION REMARK
<TRANSFORMER>
T300 1-406-781-11 COIL
T500 1-426-668-11 TRANSFORMER, FERRITE (HDT)
T501 ! 1-453-233-11 TRANSFORMER ASSY, FLYBACK
T501 * 4-058-301-01 RING, SHORT
T502 1-413-059-00 TRANSFORMER, FERRITE (DFT)
<THERMISTOR>
TH500 1-807-970-11 THERMISTOR
<OSCILLATOR>
X101 1-579-175-11 VIBRATOR, CERAMIC (10MHz)
X300 1-577-259-11 VIBRATOR, CRYSTAL (17.73MHz)
X301 1-527-722-00 VIBRATOR, CRYSTAL (14.32MHz)
*************************************************************
* A-1331-627-B C MOUNTED PWB
*************
7-682-949-01 SCREW+PSW 3X10
<CAPACITOR>
C701 1-102-157-00 CERAMIC 560PF 10% 500V
C702 1-102-157-00 CERAMIC 560PF 10% 500V
C703 1-102-157-00 CERAMIC 560PF 10% 500V
C704 1-102-121-00 CERAMIC 0.0022MF 10% 50V
C705 1-126-933-11 ELECT 100MF 20% 16V
C706 1-102-074-00 CERAMIC 0.001MF 10% 50V
C707 1-162-116-00 CERAMIC 680PF 10% 2KV
C708 1-136-601-11 FILM 0.01MF 5% 630V
C710 1-101-880-00 CERAMIC 47PF 5% 50V
C711 1-101-880-00 CERAMIC 47PF 5% 50V
C712 1-101-880-00 CERAMIC 47PF 5% 50V
C713 1-107-651-11 ELECT 4.7MF 20% 250V
C714 1-102-976-00 CERAMIC 180PF 5% 50V
C715 1-102-976-00 CERAMIC 180PF 5% 50V
C716 1-102-976-00 CERAMIC 180PF 5% 50V
C717 1-117-450-11 FILM 0.47MF 10% 250V
C718 1-117-450-11 FILM 0.47MF 10% 250V
C720 1-136-187-11 FILM 0.047MF 10% 250V
C734 1-102-973-00 CERAMIC 100PF 5% 50V
C735 1-102-816-00 CERAMIC 120PF 5% 50V
C736 1-102-816-00 CERAMIC 120PF 5% 50V
C740 1-162-114-00 CERAMIC 0.0047MF 2KV
<CONNECTOR>
CN701 * 1-564-511-11 PLUG, CONNECTOR 8P
CN702 * 1-573-964-11 PIN, CONNECTOR (PC BOARD) 6P
CN703 1-695-915-11 TAB (CONTACT)
CN704 1-695-915-11 TAB (CONTACT)
<DIODE>
D701 8-719-911-19 DIODE 1SS119-25
D702 8-719-911-19 DIODE 1SS119-25
D703 8-719-911-19 DIODE 1SS119-25
D704 8-719-911-19 DIODE 1SS119-25
D705 8-719-911-19 DIODE 1SS119-25
D706 8-719-911-19 DIODE 1SS119-25
D707 8-719-901-83 DIODE 1SS83
D708 8-719-901-83 DIODE 1SS83
D709 8-719-901-83 DIODE 1SS83
D713 8-719-901-83 DIODE 1SS83
D715 8-719-901-83 DIODE 1SS83
D716 8-719-901-83 DIODE 1SS83
D717 8-719-901-83 DIODE 1SS83
<JACK>
J701 ! 1-251-116-12 SOCKET, CRT
<COIL>
L701 1-410-667-31 INDUCTOR 22µH
L705 1-412-534-31 INDUCTOR 56µH
<TRANSISTOR>
Q701 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q702 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q703 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q704 8-729-200-17 TRANSISTOR 2SA1091-O
Q705 8-729-200-17 TRANSISTOR 2SA1091-O
Q706 8-729-200-17 TRANSISTOR 2SA1091-O
Q707 8-729-326-11 TRANSISTOR 2SC2611
Q708 8-729-326-11 TRANSISTOR 2SC2611
Q709 8-729-326-11 TRANSISTOR 2SC2611
Q710 8-729-200-17 TRANSISTOR 2SA1091-O
Q711 8-729-200-17 TRANSISTOR 2SA1091-O
Q712 8-729-200-17 TRANSISTOR 2SA1091-O
Q713 8-729-255-12 TRANSISTOR 2SC2551-O
Q714 8-729-255-12 TRANSISTOR 2SC2551-O
Q715 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q716 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q717 8-729-119-78 TRANSISTOR 2SC2785-HFE
<RESISTOR>
R702 1-247-903-00 CARBON 1M 5% 1/4W
R704 1-215-405-00 METAL 220 1% 1/4W
R705 1-215-405-00 METAL 220 1% 1/4W
R706 1-215-405-00 METAL 220 1% 1/4W
R707 1-249-431-11 CARBON 15K 5% 1/4W
R708 1-249-431-11 CARBON 15K 5% 1/4W
R709 1-249-431-11 CARBON 15K 5% 1/4W
R710 1-215-391-00 METAL 56 1% 1/4W
R711 1-215-394-00 METAL 75 1% 1/4W
R712 1-215-392-00 METAL 62 1% 1/4W
R715 1-202-818-00 SOLID 1K 20% 1/2W
R716 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R717 1-202-818-00 SOLID 1K 20% 1/2W
R718 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R719 1-202-818-00 SOLID 1K 20% 1/2W
R720 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R722 1-202-838-00 SOLID 100K 20% 1/2W
R723 1-202-838-00 SOLID 100K 20% 1/2W
R724 1-202-842-11 SOLID 220K 20% 1/2W
R725 1-202-883-11 SOLID 680K 20% 1/2W
R727 1-202-816-11 SOLID 68K 10% 1/2W
R731 1-247-815-91 CARBON 220 5% 1/4W
CA
