– 57 –
REF NO. PART NO. DESCRIPTION REMARK
REF NO. PART NO. DESCRIPTION REMARK
<FERRITE BEAD>
FB603 1-410-396-41 FERRITE 0.45µH
FB604 1-410-396-41 FERRITE 0.45µH
FB605 1-410-396-41 FERRITE 0.45µH
FB608 1-410-397-21 FERRITE 1.1µH
FB609 1-410-397-21 FERRITE 1.1µH
FB610 1-410-397-21 FERRITE 1.1µH
FB611 1-410-397-21 FERRITE 1.1µH
FB612 1-410-397-21 FERRITE 1.1µH
FB613 1-410-397-21 FERRITE 1.1µH
<IC>
IC601 8-749-925-03 IC STR-M6524
IC602 8-749-010-47 IC STR-S3115
IC603 8-759-701-56 IC NJM78M05FA
IC604 8-759-231-53 IC TA7805S
IC605 8-759-231-58 IC TA7812S
<COIL>
L601 1-411-215-11 INDUCTOR 200µH
L1601 1-410-679-31 INDUCTOR 270µH
L1602 1-421-421-00 INDUCTOR 100µH
L2601 1-459-155-00 COIL (WITH CORE) 45µH
<PHOTO INTERRUPTER >
PH601 8-749-923-50 PHOTO COUPLER PC111YS
<TRANSISTOR>
Q601 8-729-140-96 TRANSISTOR 2SD774-34
Q602 8-729-028-34 TRANSISTOR 2SD1640Q,R
Q603 8-729-303-61 TRANSISTOR 2SC3851-G
Q604 8-729-029-66 TRANSISTOR DTC114ESA
Q605 8-729-200-17 TRANSISTOR 2SA1091-O
Q606 8-729-029-66 TRANSISTOR DTC114ESA
Q607 8-729-029-66 TRANSISTOR DTC114ESA
<RESISTOR>
R601 ! 1-202-885-91 SOLID 1M 20% 1/2W
R602 1-216-491-11 METAL OXIDE 56K 5% 3W F
R603 1-216-490-11 METAL OXIDE 39K 5% 3W F
R604 1-249-418-11 CARBON 1.2K 5% 1/4W
R605 1-249-418-11 CARBON 1.2K 5% 1/4W
R606 1-207-642-00 WIREWOUND 0.15 10% 3W F
R607 1-249-426-11 CARBON 5.6K 5% 1/4W
R608 1-249-430-11 CARBON 12K 5% 1/4W
R609 1-249-430-11 CARBON 12K 5% 1/4W
R610 1-249-428-11 CARBON 8.2K 5% 1/4W
R611 1-249-417-11 CARBON 1K 5% 1/4W F
R612 1-249-404-00 CARBON 82 5% 1/4W
R613 1-249-419-11 CARBON 1.5K 5% 1/4W
R614 1-249-385-11 CARBON 2.2 5% 1/4W F
R615 ! 1-202-727-91 SOLID 4.7M 10% 1/2W
R616 1-247-863-91 CARBON 22K 5% 1/4W
R617 1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R618 1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R619 1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R620 1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R621 1-215-877-11 METAL OXIDE 22K 5% 1W F
R622 1-249-401-11 CARBON 47 5% 1/4W F
R623 1-249-417-11 CARBON 1K 5% 1/4W
R624 1-247-893-11 CARBON 390K 5% 1/4W
R625 1-216-386-11 METAL OXIDE 0.56 5% 3W F
R626 1-247-895-91 CARBON 470K 5% 1/4W
R627 1-216-490-11 METAL OXIDE 39K 5% 3W F
R628 1-216-491-11 METAL OXIDE 56K 5% 3W F
R629 ! 1-202-727-91 SOLID 4.7M 10% 1/2W
R630 1-216-490-11 METAL OXIDE 39K 5% 3W F
R631 1-249-415-11 CARBON 680 5% 1/4W F
R632 1-249-401-11 CARBON 47 5% 1/4W F
R633 1-249-429-11 CARBON 10K 5% 1/4W
R634 1-247-883-00 CARBON 150K 5% 1/4W
R635 1-249-429-11 CARBON 10K 5% 1/4W
R636 1-247-895-91 CARBON 470K 5% 1/4W
R637 1-249-424-11 CARBON 3.9K 5% 1/4W
R638 1-249-417-11 CARBON 1K 5% 1/4W
R639 1-249-419-11 CARBON 1.5K 5% 1/4W
R640 1-247-893-11 CARBON 390K 5% 1/4W
R641 1-215-423-00 METAL 1.2K 1% 1/4W
R642 1-216-391-11 METAL OXIDE 1.5 5% 3W F
R1602 1-202-842-11 SOLID 220K 20% 1/2W
R1603 1-202-842-11 SOLID 220K 20% 1/2W
<RELAY>
RY601 ! 1-515-738-11 RELAY
<TRANSFORMER>
T601 ! 1-426-716-11 TRANSFORMER, LINE FILTER (LFT)
T602 ! 1-426-716-11 TRANSFORMER, LINE FILTER (LFT)
T603 1-431-630-11 TRANSFORMER, CONVERTER (SRT)
<THERMISTOR(POSITIVE) >
THP601 ! 1-808-059-32 THERMISTOR, POSITIVE
<VARISTOR>
VDR601! 1-809-942-81 VARISTOR (430V)
VDR602 1-809-942-71 VARISTOR (430V)
*************************************************************
* A-1372-477-A H MOUNT
********
* 4-348-208-00 HOLDER, LED
<CONNECTOR>
CN105 * 1-564-527-11 PLUG, CONNECTOR 12P
CN106 * 1-564-526-11 PLUG, CONNECTOR 11P
<DIODE>
D2102 8-719-920-05 DIODE SLP281C-50
D2103 8-719-812-32 DIODE TLY123
D2104 8-719-991-33 DIODE 1SS133T-77
<RESISTOR>
R2101 1-249-419-11 CARBON 1.5K 5% 1/4W
R2107 1-249-430-11 CARBON 12K 5% 1/4W
R2136 1-249-414-11 CARBON 560 5% 1/4W
