Appendixes A-1
3-810-005-11(1)Letter Ver.3.0
Appendixes
Specifications
Appendixes
C-74 Microphone
CRS-3P Cradle Suspension
BVF-10/10CE 1.5-inch Viewfinder
VCT-14 Tripod Adaptor
Design and specifications are subject to change
without notice.
General
Operating temperature
–20 °C to +45 °C (–4°F to +113°F)
Storing temperature
–20 °C to +50 °C (–4°F to +122°F)
Mass Approx. 3.2 kg (7 lb 1 oz)
Dimensions 115 × 290 × 284mm (W/H/D)
(4
5
/8 × 11
1
/2 × 11
1
/4 inches)
Input/output signals
Video output NTSC/PAL 1.0 Vp-p, synchronous
load, 75 ohms, unbalanced, two
outputs (TEST OUT and camera
adaptor IF connectors)
Input/output connectors
Camera adaptor I/F 68-pin (video
output, microphone output, sync
signal output, power supply input,
× 2
TEST OUT: BNC-type
LENS: 12-pin
REMOTE: 6-pin
VF: 20-pin
MIC: 3-pin (female)
For details on the specifications of the attached CCD unit,
refer to the installation guide supplied with the CCD unit.
Supplied accessories
Operation Manual (1)
Maintenance Manual (1)
Optional accessories
OHB-450/450P/451/451P/550/550P/550WS/550WSP
CCD Unit
CA-550/550P Camera Adaptor
CA-553 Betacam Adaptor
BKDW-701 Servo Filter Unit
BKW-401 Viewfinder Rotation Bracket
RM-P9 Remote Control Unit
BVF-55/55CE 5-inch Viewfinder
Extension board EX-464 (J-6395-040-A)
LC-303SFT Soft Case
