Sony C2104 - Table of Contents

Working Instruction Repair Instruction Mechanical/
1273-2279 Rev3

Sony Mobile Communications AB – Company Internal
2(50)
CONTENTS
1 Exterior Views ................................................................................. 4
1.1 C2104, C2105, S36h ............................................................................... 4
2 Tools ................................................................................................ 5
3
Disassembly .................................................................................... 6
3.1 Battery Cover ......................................................................................... 6
Disassembly .......................................................................................... 7
3.2 Battery .................................................................................................... 7
3.3
Middle Frame Assembly ....................................................................... 8
3.4
Sub PBA assembly .............................................................................. 10
3.5
Main PBA (a) & RF Cable (b) .............................................................. 11
3.6
Front Housing LCM TP Assembly ..................................................... 12
4 Replacement ................................................................................. 14
4.1 Battery Cover ....................................................................................... 14
4.2
Middle Frame Assembly ..................................................................... 14
4.3
Sub PBA Assembly ............................................................................. 14
4.4
Front Housing LCM TP Assembly ..................................................... 14
4.5
Conductive cloth for TP IC ................................................................. 15
4.6
Conductive cloth Main camera .......................................................... 16
4.7
CU Label ............................................................................................... 17
4.8
Screw .................................................................................................... 17
4.9
Film Main Camera ................................................................................ 18
4.10
Film RF Cable ...................................................................................... 18
4.11
Film RF Hole ........................................................................................ 19
4.12
Film Side Key ....................................................................................... 20
4.13
NFC Antenna ........................................................................................ 21
4.14
Loudspeaker & Speaker Adhesive .................................................... 22
4.15
Main Camera ........................................................................................ 24
4.16
Rubber PL Sensor ............................................................................... 27
4.17
Earspeaker & Receiver Adhesive ...................................................... 28
4.18
RF Cable ............................................................................................... 30
4.19
Rubber 2nd MIC ................................................................................... 31
4.20
Power Key ............................................................................................ 32
4.21
Rubber Main MIC ................................................................................. 33
4.22
Water Intrusion Label .......................................................................... 34
4.23
Label NFC ............................................................................................. 35
4.24 TP IC Adhesive
.................................................................................... 36
4.24
Board Swap – Replacement .............................................................. 37
4.25
Board Swap – Change Label .............................................................. 37
4.26
Board Swap – Customize of Software ............................................... 37
