SAFETY CHECK-OUT
After correcting the original service problem, perform
the following safety check before releasing the set to the
customer :
Check the antenna terminals, metal trim, ” metallized”
knobs, screws, and all other exposed metal parts for AC
leakage. Check leakage as described below.
LEAKAGE TEST
- The AC leakage from any exposed metal part to earth
ground and from all exposed metal parts to any exposed
metal part having a return to chassis, must not exceed
0.5 mA (500 microampers.).
Leakage current can be measured by any one of three
methods.
1. A commercial leakage tester, such as the Simpson
229 or RCA WT-540A. Follow the manufacturers’
instructions to use these instruments.
2. <A battery-operated AC milliammeter. The Data
Precision 245 digital multimeter is suitable for this
job.
3. Measuring the voltage drop across a resistor by
means of a VOM or battery-operated AC volt-
meter. The “limit” indication is 0.75V, so analog
meters must have an accurate low-voltage scale.
The Simpson 250 and Sanwa SH-63Trd are
examples of a passive VOM that is suitable. Nearly
all battery operated digital multimeters that have a
2V AC range are suitable. (See Fig. A)
To Exposed Metal
Parts on Set
AC
Voltmeter
(0.75V)
= Earth Ground
Fig. A. Using an AC voltmeter to check AC leakage.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK /{\ OR DOTTED LINE
WITH MARK /\ ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
TABLE OF CONTENTS
Section Title Page
* GENERAL sire neitiaignas seer ees 4
2. DISASSEMBLY
3. ELECTRICAL BLOCK CHECKING --------------+- 6
4. IC PIN DESCRIPTION .---- 0. eee eee eee eee eens 8
5. DIAGRAMS
5-1, Block Diagram re ee ee ee 2 “ene 12
5-2. Printed Wiring Boards (New Type) -vresr tree's: 15
5.3, Schematic Diagram Parr e e 19
54, Printed Wiring Boards (Former Type) ::::-++:°: 23
5-5. Semiconductor Lead Layouts --+rr+scrr errs teen 28
6. EXPLODED VIEWS
6-1. Front Panel Section «:+rterree: @ Bie ferteie ate cat atierteiasee evene 29
6-2. CD Mechanism Section (CDM14-5BD10) :-:+++-:: 31
6-3. Optical Pick-up Block (BU-5BD10) «++-++++++++:- 32
7. ELECTRICAL PARTS LIST -vereccr terete eer eees 33
MODEL IDENTIFICATION
—CDP-211
CDP-311
SON Yo MODEL noZ Yl
COMPACT DISC PLAYER
SERIAL NO,
MADE IN JAPAN.
US, Canadian Model: AC 120V 60Hz 10W
AEP Model: AC 220-230V.~50/60Hz 10W
Australian Model: AC 240V ~ 50/60Hz
E, Saudi Alabia Model: AC 110-120V, 220-240V,
~ 50/60Hz 10W
CDP-211
COP-311
SON Yo MODEL NO WWW
COMPACT DISC PLAYER
MMMM
SERIAL NO.
MADE IN FRANCE
AEP, Germany Model: AC 220-230V ~ 50/60Hz 10W
UK Model: AC240v ~ 50/60Hz
ATTENTION AU COMPOSANT AYANT
RAPPORT A LA SECURITE!
LES COMPOSANTS IDENTIFIES PAR UNE MARQUE /\
SUR LES DIAGRAMMES SCHEMATIQUES ET LA LISTE DES
PIECES SONT CRITIQUES POUR LA SECURITE DE
FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS
QUE PAR DES PIECES SONY DONT LES NUMEROS SONT
DONNES DANS CE MANUEL OU DANS LES SUPPLEMENTS
PUBLIES PAR SONY.
