Sony CDX-5V661A - L Motor Assy (Loading) (M103); Chassis (TR) Main Assy

CDX-5V661/5V661A/5V661D/5V661S
9
2-8. L MOTOR ASSY (LOADING) (M103)
2-9. CHASSIS (TR) MAIN ASSY
2 bracket (damper R) assy
1 two screws (M2
)
1 two screws (M2)
5 two screws (M1.7)
(P2)
8 two screws
(P2
× 2)
6 screw (M2)
9 bracket (HL) assy
3 cushion
(unweaved cloth)
0 L motor assy
(loading) (M103)
4 connector
(CN501)
7
5 screw (M2)
3 three screws
(M2)
4 screw (M1.7) (P2)
5 screw (M2)
A
4 two screws (M1.7) (P2)
1 screw (M2)
3 two screws
(M2)
4 screw (M1.7) (P2)
7 chassis (TR) main assy
Note: To install the chassis (TR) main assy,
turn the lever (EJL) and the lever (EJR) in the
direction of each arrow, hold them, and
put
a
of the lever (EJL) upon the edge pointed
by arrow
A .
6 boss
2 washer
6 boss
lever (EJR)
lever (EJL)
a
