8
CDX-MP50
2-2. CD MECHANISM BLOCK
2-3. MAIN BOARD
1
PTT 2.6x6
6
PTT 2.6x
6
7
bracket (CD)
2
PTT 2.6x6
5
CD mechanism block
4
CNP701
3
1
PTT 2.6x8
2
PTT 2.6x
8
3
screw (+BTT)
4
screws (+BTT)
5
MAIN board
