Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
13
CDX-T67
< CONNECTOR >
CN101 1-793-820-21 CONNECTOR, FPC 22P
CN102 1-815-016-21 CONNECTOR, FFC/FPC (ZIF) 16P
< IC >
IC101 8-752-089-74 IC CXA2581N-T4
IC201 8-759-832-99 IC LA6576L-TE-L
< TRANSISTOR >
Q101 8-729-141-48 TRANSISTOR 2SB624T1-BV345
Q102 8-729-901-00 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R103 1-216-801-11 METAL CHIP 22 5% 1/16W
R106 1-216-845-11 METAL CHIP 100K 5% 1/16W
R109 1-216-845-11 METAL CHIP 100K 5% 1/16W
R110 1-216-836-11 METAL CHIP 18K 5% 1/16W
R111 1-216-833-11 METAL CHIP 10K 5% 1/16W
R112 1-216-833-11 METAL CHIP 10K 5% 1/16W
R113 1-216-834-11 METAL CHIP 12K 5% 1/16W
R114 1-216-833-11 METAL CHIP 10K 5% 1/16W
R115 1-216-835-11 METAL CHIP 15K 5% 1/16W
R116 1-216-845-11 METAL CHIP 100K 5% 1/16W
R117 1-218-859-11 METAL CHIP 3.3K 0.5% 1/16W
R118 1-218-879-11 METAL CHIP 22K 0.5% 1/16W
R119 1-218-847-11 METAL CHIP 1K 0.5% 1/16W
R120 1-216-837-11 METAL CHIP 22K 5% 1/16W
R121 1-216-837-11 METAL CHIP 22K 5% 1/16W
R127 1-216-801-11 METAL CHIP 22 5% 1/16W
R128 1-218-847-11 METAL CHIP 1K 0.5% 1/16W
R201 1-216-833-11 METAL CHIP 10K 5% 1/16W
R202 1-216-833-11 METAL CHIP 10K 5% 1/16W
R203 1-216-833-11 METAL CHIP 10K 5% 1/16W
R204 1-216-839-11 METAL CHIP 33K 5% 1/16W
R205 1-216-833-11 METAL CHIP 10K 5% 1/16W
R206 1-216-839-11 METAL CHIP 33K 5% 1/16W
R207 1-216-833-11 METAL CHIP 10K 5% 1/16W
R208 1-216-839-11 METAL CHIP 33K 5% 1/16W
R209 1-216-833-11 METAL CHIP 10K 5% 1/16W
R210 1-216-839-11 METAL CHIP 33K 5% 1/16W
R211 1-216-841-11 METAL CHIP 47K 5% 1/16W
R212 1-216-843-11 METAL CHIP 68K 5% 1/16W
R213 1-216-841-11 METAL CHIP 47K 5% 1/16W
R214 1-216-842-11 METAL CHIP 56K 5% 1/16W
R215 1-216-833-11 METAL CHIP 10K 5% 1/16W
R216 1-216-839-11 METAL CHIP 33K 5% 1/16W
R218 1-216-833-11 METAL CHIP 10K 5% 1/16W
R219 1-216-839-11 METAL CHIP 33K 5% 1/16W
R220 1-216-834-11 METAL CHIP 12K 5% 1/16W
R222 1-216-821-11 METAL CHIP 1K 5% 1/16W
R223 1-216-820-11 METAL CHIP 820 5% 1/16W
< SWITCH >
SW101 1-571-754-31 SWITCH, PUSH (1KEY) (LIMIT)
SW102 1-786-149-21 SWITCH, PUSH (1KEY)
(CHUCKING END DETECT)
RF
