Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
57
CFD-E95
C323 1-126-795-11 ELECT 10uF 20% 50V
C324 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C333 1-126-796-11 ELECT 22uF 20% 25V
C901 1-162-995-11 CERAMIC CHIP 2200PF 50V
(US, E)
C901 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(EXCEPT US, E)
C902 1-162-995-11 CERAMIC CHIP 2200PF 50V
(US, E)
C902 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(EXCEPT US, E)
C903 1-162-995-11 CERAMIC CHIP 2200PF 50V
(US, E)
C903 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(EXCEPT US, E)
C904 1-162-995-11 CERAMIC CHIP 2200PF 50V
(US, E)
C904 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(EXCEPT US, E)
C906 1-126-795-11 ELECT 10uF 20% 50V
C910 1-126-937-11 ELECT 4700uF 20% 16V
C912 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C913 1-126-382-11 ELECT 100uF 20% 10V
C953 1-126-382-11 ELECT 100uF 20% 16V
C954 1-126-935-11 ELECT 470uF 20% 10V
C955 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C956 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C958 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
* CNP901 1-815-444-11 PIN, CONNECTOR (PWB) 3P
< DIODE >
D323 8-719-988-61 DIODE 1SS355TE-17
D901 8-719-063-79 DIODE 1N4002B
D902 8-719-063-79 DIODE 1N4002B
D903 8-719-063-79 DIODE 1N4002B
D904 8-719-063-79 DIODE 1N4002B
D905 8-719-058-24 DIODE RB501V-40TE-17
D906 8-719-056-73 DIODE UDZ-TE-17-2.7B
D907 8-719-988-61 DIODE 1SS355TE-17
D910 8-719-988-61 DIODE 1SS355TE-17
D953 8-719-978-33 DIODE UDZSTE-176.8B
D954 8-719-978-33 DIODE UDZSTE-176.8B
D956 8-719-988-61 DIODE 1SS355TE-17
< FUSE >
0F901 1-533-469-11 FUSE, GLASS TUBE (DIA. 5) (T2.5AL/250V)
(EXCEPT US, E)
< IC >
IC304 8-759-426-51 IC BA5417
IC910 6-703-285-01 IC S-812C33AUA-C2NT2G
< SHORT >
JC301 1-216-864-11 SHORT CHIP 0
< COIL >
L910 1-414-142-61 INDUCTOR 1uH
< TRANSISTOR >
Q124 8-729-029-10 TRANSISTOR DTC143TUA-T106
Q224 8-729-029-10 TRANSISTOR DTC143TUA-T106
Q952 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q953 8-729-905-34 TRANSISTOR 2SC4081T106Q
Q954 8-729-028-54 TRANSISTOR KTC3205-Y-AT
Q955 8-729-018-99 TRANSISTOR 2SD2394-F
< RESISTOR >
R130 1-216-813-11 METAL CHIP 220 5% 1/10W
R131 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R142 1-216-817-11 METAL CHIP 470 5% 1/10W
R144 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R230 1-216-813-11 METAL CHIP 220 5% 1/10W
R231 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R242 1-216-817-11 METAL CHIP 470 5% 1/10W
R244 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R323 1-216-857-11 METAL CHIP 1M 5% 1/10W
R324 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R333 1-216-821-11 METAL CHIP 1K 5% 1/10W
R901 1-216-805-11 METAL CHIP 47 5% 1/10W
R950 1-216-841-11 METAL CHIP 47K 5% 1/10W
R951 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R952 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R953 1-216-821-11 METAL CHIP 1K 5% 1/10W
R954 1-216-821-11 METAL CHIP 1K 5% 1/10W
R955 1-216-833-11 METAL CHIP 10K 5% 1/10W
R956 1-216-821-11 METAL CHIP 1K 5% 1/10W
R957 1-216-821-11 METAL CHIP 1K 5% 1/10W
R961 1-216-821-11 METAL CHIP 1K 5% 1/10W
R962 1-216-821-11 METAL CHIP 1K 5% 1/10W
R968 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R969 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< TRANSFORMER >
0T901 1-439-712-11 TRANSFORMER, POWER
(EXCEPT SP, KR, AUS)
0T901 1-439-713-11 TRANSFORMER, POWER (SP, KR, AUS)
**************************************************************
* A-3663-824-A RELAY BOARD, COMPLETE
**********************
< CONNECTOR >
* CNP322 1-815-552-11 PIN, CONNECTOR (PWB) 4P
* CNP324 1-815-553-11 PIN, CONNECTOR (PWB) 5P
CNP325 1-815-443-11 PIN, CONNECTOR (PWB) 2P
CNP326 1-815-443-21 PIN, CONNECTOR (PWB) 2P
**************************************************************
* A-3683-864-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
POWER RELAY TC
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Ver 1.2
