Sony CFD-G30 - Specifications

Additional Information 33
Specifications
General
Speaker
Full range: 10 cm (4
in.) dia., 3.2 ohms,
cone type (2)
Woofer: 8 cm (3
1
⁄4 in.) dia., 4 ohms, cone type (1)
Inputs
LINE IN (stereo minijack): Sensitivity 436 mV
Outputs
Headphones jack (stereo minijack)
For 16 - 68 ohms impedance headphones
Power output (excluding for US model)
Full range:
4 W + 4 W (at 3.2 ohms, 10 % harmonic distortion
in DC operation)
Woofer:
12 W (at 4 ohms, 10 % harmonic distortion
in DC operation)
Power requirements
For CD radio cassette-corder:
120 V AC, 60 Hz
12 V DC, 8 size D (R20) batteries
For remote control (CFD-G50 only):
3 V DC, 2 size AA (R6) batteries
Power consumption
AC 30 W
Battery life
For CD radio cassette-corder:
FM recording
Sony R20P: approx. 8 h
Sony alkaline LR20: approx. 18 h
Tape playback
Sony R20P: approx. 1.5 h
Sony alkaline LR20: approx. 6 h
CD playback
Sony R20P: approx. 1 h
Sony alkaline LR20 : approx. 4 h
Dimensions
Approx. 500 × 206 × 328 mm (w/h/d)
(19
3
⁄4 × 8
1
⁄8 × 13 inches) (incl. projecting parts)
Mass
Approx. 7 kg (15 lb. 7 oz) (incl. batteries)
Supplied accessories
AC power cord (1)
Remote control (1) (CFD-G50 only)
Design and specifications are subject to change without
notice.
Optional accessories
Sony MDR headphones series
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION
With 3.2-ohm loads, both channels driven
from 1,000 - 10,000 Hz; rated 3 W per
channel-minimum RMS power, with no more
than 10 % total harmonic distortion in AC
operation.
Woofer with 4-ohm loads, driven at
50 - 150 Hz; rated 6 W minimum RMS power,
with no more 10 % total harmonic distortion
in AC operation.
Other Specifications
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wave length: 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a distance of
about 200 mm from the objective lens surface on
the optical pick-up block with 7 mm aperture.)
Spindle speed
200 r/min (rpm) to 500 r/min (rpm) (CLV)
Number of channels
2
Frequency response
20 - 20,000 Hz +0.5/–1.5 dB
Wow and flutter
Below measurable limit
Radio section
Frequency range
FM: 87.6 - 108 MHz
AM: 530 - 1,710 kHz
Antennas
FM: Telescopic antenna
AM: Built-in ferrite bar antenna
Cassette-corder section
Recording system
4-track 2 channel stereo
Fast winding time
Approx. 110 sec. with Sony cassette C-60
Frequency response
TYPE I (normal): 70 - 13,000 Hz
