59
CFD-S35CP
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R766 1-216-797-11 METAL CHIP 10 5% 1/10W
R1001 1-216-809-11 METAL CHIP 100 5% 1/10W
R1002 1-216-809-11 METAL CHIP 100 5% 1/10W
R1003 1-216-809-11 METAL CHIP 100 5% 1/10W
R1004 1-216-809-11 METAL CHIP 100 5% 1/10W
R1005 1-216-809-11 METAL CHIP 100 5% 1/10W
R1017 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1018 1-216-809-11 METAL CHIP 100 5% 1/10W
R1019 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1020 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1068 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1073 1-216-809-11 METAL CHIP 100 5% 1/10W
R1074 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1075 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1076 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1077 1-216-809-11 METAL CHIP 100 5% 1/10W
R1078 1-216-809-11 METAL CHIP 100 5% 1/10W
R1079 1-216-809-11 METAL CHIP 100 5% 1/10W
R1080 1-216-809-11 METAL CHIP 100 5% 1/10W
R1081 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1082 1-216-805-11 METAL CHIP 47 5% 1/10W
< SWITCH >
S701 1-571-936-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X701 1-795-563-21 VIBRATOR, CERAMIC (16.9MHz)
*************************************************************
* 1-725-705-11 POWER BOARD
*************
1-533-233-31 HOLDER, FUSE
< CAPACITOR >
C901 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C902 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C903 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C904 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C906 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CNP901 1-815-551-11 PIN, CONNECTOR (PWB) 3P
< DIODE >
D901 8-719-063-79 DIODE 1N4002B
D902 8-719-063-79 DIODE 1N4002B
D903 8-719-063-79 DIODE 1N4002B
D904 8-719-063-79 DIODE 1N4002B
< FUSE >
0 F902 1-533-468-12 FUSE, GLASS TUBE (DIA. 5) (T2AL/250V)
(EXCEPT MX)
0 F902 1-533-469-12 FUSE, GLASS TUBE (DIA. 5) (2.5A/250V)(MX)
< AC INLET >
0 J901 1-526-818-11 INLET, AC (- AC IN) (MX)
0 J901 1-526-838-11 INLET, AC 2P (- AC IN) (EXCEPT MX)
< TRANSFORMER >
0 T901 1-435-917-21 TRANSFORMER, POWER (MX)
0 T901 1-435-918-21 TRANSFORMER, POWER (EXCEPT MX)
*************************************************************
A-1101-717-A POWER KEY BOARD, COMPLETE
**************************
< RESISTOR >
R401 1-216-813-11 METAL CHIP 220 5% 1/10W
R402 1-216-817-11 METAL CHIP 470 5% 1/10W
< SWITCH >
S401 1-786-050-21 SWITCH, KEYBOARD (OPERATE)
S402 1-786-050-21 SWITCH, KEYBOARD (SLEEP)
*************************************************************
A-1108-791-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C102 1-104-658-11 ELECT 100uF 20% 10V
C103 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C104 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C105 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C107 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C201 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C202 1-104-658-11 ELECT 100uF 20% 10V
C203 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C204 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C205 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C207 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C301 1-104-658-11 ELECT 100uF 20% 10V
C302 1-104-658-11 ELECT 100uF 20% 10V
C303 1-104-658-11 ELECT 100uF 20% 10V
C304 1-126-947-11 ELECT 47uF 20% 35V
C305 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C306 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C307 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C308 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C310 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
< CONNECTOR >
CN303 1-784-774-11 CONNECTOR, FFC 13P
< IC >
IC301 8-759-264-71 IC TA2068N
< JUMPER RESISTOR >
JC301 1-216-864-11 SHORT CHIP 0
JC302 1-216-864-11 SHORT CHIP 0
JC303 1-216-864-11 SHORT CHIP 0
POWERMP3-CD POWER KEY TC
Ver. 1.1
