If option 1 has been chosen, the following display will appear:
Flash ROM Type – Sharp 30 23
Set the switch of the voltage convertor as follows.
Vpp = on; FROMRP = off
After you set the switch, type any key to proceed.
The user is requested to set the switches on the Level Shifter to the settings displayed.
To enable the ROM Loader Software to determine the ROM manufacturer and hence the switch settings, the
ROM−ID is read first from the Z1. The settings shown in the sample above are only valid for a Sharp ROM and
are therefore only an example. Future ROM types may come from a different manufacturer. After setting the
switches on the Level Shifter, press any key to proceed.
NOTE If the connection has been set up successfully, the green lamp on the Z1 display starts flashing.
As soon as the connection is established successfully, the current AP and OS software versions are displayed
as well as the latest versions to ensure that the service operator is fully aware oft he differences of both software
versions.
Proceeding the program leads to the following simple options from which the operator is requested to choose:
– Update AP? (y/n/c) or
– Update OS? (y/n/c) or
– Change Language Set? (y/n/c)
*
The operator does not have to change the Language Set or any other item he does not want to change at this
time. Thus it is possible to change the operating system (OS) only while the application code (AP) and the
Language Set remain unchanged.
NOTE Typing in “c” (cancel) will interrupt the updating process at any time and will abandon the program.
* The request to update AP(y) makes a language set change necessary.
Therefore the message : “Default new language setting because of AP code change”, appears instead
of “change language set” (y/n/c)
9
