17
D-E340/E341
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
When indicating parts by reference num-
ber, please include the board.
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
* A-3347-654-A MAIN BOARD, COMPLETE (E340:AEP,E341)
* A-3347-990-A MAIN BOARD, COMPLETE (E340:E)
*******************
3-222-860-01 TERMINAL (+.-), BATTERY
3-231-411-01 TERMINAL (-), BATTERY
3-244-913-11 LEAF (B), COPPER
3-253-540-01 LEAF (A), COPPER
< CAPACITOR >
C103 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C203 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C204 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-100-053-21 ELECT CHIP 220uF 20% 6.3V
C303 1-115-156-11 CERAMIC CHIP 1uF 10V
C304 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C305 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C306 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C307 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C402 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C403 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C404 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C405 1-115-156-11 CERAMIC CHIP 1uF 10V
C406 1-126-369-11 ELECT 220uF 20% 6.3V
C407 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C408 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C409 1-113-689-11 ELECT CHIP 100uF 20% 4V
C410 1-113-689-11 ELECT CHIP 100uF 20% 4V
C412 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C414 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C415 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C416 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C417 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C418 1-126-369-11 ELECT 220uF 20% 6.3V
C419 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C420 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C421 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C422 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C423 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C424 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C427 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C428 1-135-854-21 ELECT CHIP 10uF 20% 16V
C429 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C430 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C432 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C437 1-115-156-11 CERAMIC CHIP 1uF 10V
C438 1-115-156-11 CERAMIC CHIP 1uF 10V
C450 1-115-156-11 CERAMIC CHIP 1uF 10V
C451 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C452 1-115-156-11 CERAMIC CHIP 1uF 10V
C453 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C462 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C463 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C481 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C482 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C500 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C501 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C502 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C601 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C602 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C603 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C604 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C605 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C606 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C607 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C608 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C609 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C610 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C611 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C612 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C613 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C614 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C615 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C616 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
C617 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C618 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C619 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C620 1-115-156-11 CERAMIC CHIP 1uF 10V
C621 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C622 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C623 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
