26
D-E666/EJ620/EJ621/EJ622/EJ623/EJ625/EJ626CK
R645 1-216-819-11 METAL CHIP 680 5% 1/16W
R650 1-216-864-91 SHORT 0 (EXCEPT US)
R653 1-216-864-91 SHORT 0
R654 1-216-864-91 SHORT 0
R655 1-216-841-11 METAL CHIP 47K 5% 1/16W
R656 1-216-847-11 METAL CHIP 150K 5% 1/16W
R657 1-216-864-91 SHORT 0 (US)
R658 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R659 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R660 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R661 1-216-845-11 METAL CHIP 100K 5% 1/16W
R801 1-216-837-11 METAL CHIP 22K 5% 1/16W
R802 1-216-837-11 METAL CHIP 22K 5% 1/16W
R803 1-216-843-11 METAL CHIP 68K 5% 1/16W
R807 1-216-845-11 METAL CHIP 100K 5% 1/16W
(FR)
R807 1-216-851-11 METAL CHIP 330K 5% 1/16W
(EXCEPT FR)
R809 1-216-845-11 METAL CHIP 100K 5% 1/16W
R811 1-216-864-91 SHORT 0
R812 1-216-864-91 SHORT 0
R813 1-216-837-11 METAL CHIP 22K 5% 1/16W
(US)
R813 1-216-839-11 METAL CHIP 33K 5% 1/16W
(EXCEPT US, FR)
R813 1-216-847-11 METAL CHIP 150K 5% 1/16W
(FR)
R814 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EJ620/EJ621/EJ622/EJ623/EJ625:US,
CND,AEP,UK,G,FR,EE/EJ626CK)
R818 1-216-843-11 METAL CHIP 68K 5% 1/16W
(FR)
R818 1-216-847-11 METAL CHIP 150K 5% 1/16W
(EXCEPT US, FR)
R819 1-216-833-11 METAL CHIP 10K 5% 1/16W
R820 1-216-857-11 METAL CHIP 1M 5% 1/16W
(E666/EJ625:E13,HK,KR,CH,AUS)
R824 1-216-833-11 METAL CHIP 10K 5% 1/16W
R826 1-216-841-11 METAL CHIP 47K 5% 1/16W
(FR)
R826 1-216-849-11 METAL CHIP 220K 5% 1/16W
(EXCEPT US, FR)
R826 1-216-851-11 METAL CHIP 330K 5% 1/16W
(US)
R827 1-216-864-91 SHORT 0
R828 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R831 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EJ620/EJ621/EJ622/EJ623/EJ625:US,
CND,AEP,UK,G,FR,EE/EJ626CK)
R841 1-216-849-11 METAL CHIP 220K 5% 1/16W
R842 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R843 1-216-833-11 METAL CHIP 10K 5% 1/16W
R846 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R900 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(EJ626CK: EXCEPT US)
R901 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(EJ626CK: EXCEPT US)
<SWITCH>
S801 1-692-440-11 SWITCH, PUSH (DOOR OPEN)
S802 1-762-078-11 SWITCH, SLIDE (AVLS)
S803 1-762-078-11 SWITCH, SLIDE (HOLD)
S804 1-553-977-00 SWITCH, SLIDE (G PROTECTION)
S805 1-771-482-11 SWITCH, PUSH (1 KEY) (VOLUME +)
S806 1-771-482-11 SWITCH, PUSH (1 KEY) (VOLUME –)
<VIBRATOR>
X601 1-795-101-21 VIBRATOR, CERAMIC (16.9MHz) (EXCEPT US)
X601 1-795-218-21 VIBRATOR, CERAMIC (16.9MHz) (US)
***********************************************************************
MISCELLANEOUS
***************
14 1-476-261-11 SWITCH UNIT (E666/EJ620/EJ621/EJ622/
EJ623/EJ625/EJ626CK:US)
14 1-476-261-21 SWITCH UNIT
(EJ626CK:CND,AEP,UK,G,E33,C&SA,AUS)
0 60 X-4952-506-1 OPTICAL PICK-UP (DAX-23E)
M901 A-3328-760-A MOTOR ASSY, TURN TABLE (SPINDLE)
M902 A-3328-627-A MOTOR ASSY (SLED) (INCLUDING GEAR)
***********************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
X-3373-432-1 BRACKET ASSY (EJ626CK:CND,AEP,UK,G)
1-251-696-21 CONNECTING PACK, CAR (EJ626CK)
0 1-418-262-22 ADAPTOR, AC (AC-E455G)
(EJ621:AEP,UK,G,FR,EE,E13/EJ623/
EJ625:AEP,G,FR,EE,E13/EJ626CK:AEP,G)
0 1-418-264-11 ADAPTOR, AC (AC-E455A) (AUS)
1-418-670-11 REMOTE CONTROL UNIT (RM-CD6)
(EJ621:AR,MX/EJ625:US,CND,AEP,UK,G,FR,EE)
1-418-897-11 ROTARY COMMANDER
(EJ626CK:CND,AEP,UK,G)
0 1-467-009-21 ADAPTOR, AC (AC-E455)
(EJ621:US,CND,CCND,C&SA,MX/
EJ622/EJ625:US,CND,TW/
EJ626CK:US,CND,C&SA)
0 1-467-550-11 ADAPTOR, AC (AC-E455A) (JEW,E33)
0 1-473-115-11 ADAPTOR, AC (AC-E455F) (UK)
0 1-473-116-35 ADAPTOR, AC (AC-E455D)
(EJ621:AEP,UK,G,FR,EE,E13,EJ623/EJ625:
AEP,UK,G,FR,EE,E13/EJ626CK:AEP,G)
0 1-475-622-11 ADAPTOR, AC (AC-E455) (CH)
0 1-475-623-11 ADAPTOR, AC (AC-E455) (EJ625:HK)
0 1-475-969-11 ADAPTOR, AC (AC-E455) (EJ621:AR)
1-476-373-21 REMOTE CONTROL UNIT
(E666/EJ625:E13,HK,KR,CH,AUS)
0 1-476-739-11 ADAPTOR, AC (AC-E455) (KR)
0 1-569-007-11 ADAPTOR, CONVERSION 2P (JEW,E33)
1-756-158-11 BATTERY PACK (NC-WMAA)
(E666/EJ625:E13,HK,KR,CH,AUS)
1-756-158-21 BATTERY PACK
(EJ623/EJ625:AEP,UK,G,FR,EE)
1-756-158-31 BATTERY PACK (EJ625:US,CND)
1-784-619-71 CORD, CAR BATTERY (EJ626CK)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MAIN
Ver 1.3 2001.07
