22
D-E666/EJ620/EJ621/EJ622/EJ623/EJ625/EJ626CK
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
Les composants identifiés par une
marque 0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board.
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3021-504-A MAIN BOARD, COMPLETE (EJ626CK: FR)
* A-3323-654-A MAIN BOARD, COMPLETE
(EJ626CK: EXCEPT US,FR)
* A-3323-656-A MAIN BOARD, COMPLETE
(EJ620,EJ621,EJ625: FR)
* A-3323-657-A MAIN BOARD, COMPLETE
(EXCEPT US,FR/EJ626CK)
* A-3323-658-A MAIN BOARD, COMPLETE (US)
**************************
<BATTERY TERMINAL>
BT400 4-223-585-01 TERMINAL BOARD (+), BATTERY
BT401 3-222-024-01 TERMINAL BOARD (RELAY),BATTERY
BT402 3-222-023-01 TERMINAL (–), BATTERY
<CAPACITOR>
C1 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C101 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C102 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C103 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C110 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C122 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C123 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C124 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C201 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C202 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C203 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C204 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C210 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C222 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C223 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C224 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C300 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EJ620/EJ621/EJ622/EJ623/EJ625:US,
CND,AEP,UK,G,FR,EE/EJ626CK)
C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C313 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(E666/EJ625:E13,HK,KR,CH,AUS)
C351 1-115-156-11 CERAMIC CHIP 1uF 10V
(E666/EJ625:E13,HK,KR,CH,AUS)
C351 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(EJ620/EJ621/EJ622/EJ623/EJ625:US,
CND,AEP,UK,G,FR,EE/EJ626CK)
C352 1-124-261-00 ELECT 10uF 20% 50V
C353 1-124-261-00 ELECT 10uF 20% 50V
(E666/EJ625:E13,HK,KR,CH,AUS)
C353 1-126-162-11 ELECT 3.3uF 20% 50V
(EJ620/EJ621/EJ622/EJ623/EJ625:US,
CND,AEP,UK,G,FR,EE/EJ626CK)
C354 1-128-057-11 ELECT 330uF 20% 6.3V
C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C402 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C403 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C404 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
(E666/EJ625:E13,HK,KR,CH,AUS)
C405 1-115-156-11 CERAMIC CHIP 1uF 10V
C406 1-128-057-11 ELECT 330uF 20% 6.3V
C407 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C408 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C409 1-124-584-00 ELECT 100uF 20% 10V
C410 1-124-635-00 ELECT 220uF 20% 6.3V
C411 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C412 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C414 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C415 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C416 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C417 1-110-569-11 TANTAL. CHIP 47uF 20% 4V
C418 1-124-635-00 ELECT 220uF 20% 6.3V
C419 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C420 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C421 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C422 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C423 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C424 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C425 1-115-156-11 CERAMIC CHIP 1uF 10V
C426 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
• Abbreviation
CND : Canadian AUS : Australian
FR : French HK : Hong Kong
AR : Argentina JE : Tourist
G : German EE : East European
CH : Chinese EA : Saudi Arabia
CCND : Canadian (Clam shell package)
C&SA : Central and South America
AEP7 : AEP (Without AC adaptor)
3AEP7: UK
E13 : AC220-230V area model
E33 : AC100-240V area model
MAIN
Ver 1.3 2001.07
