D-E666/EJ620/EJ621/EJ622/EJ623/EJ625/EJ626CK
* 7 A-3323-654-A MAIN BOARD, COMPLETE A-3021-504-A MAIN BOARD, COMPLETE
D-EJ626CK (AEP MODEL) D-EJ626CK (French MODEL)
Ref. No. Part No. Description Part No. Description
• DEFFERENCE PARTS LIST
EXPLODED VIEWS
CABINET SECTION (Service Manual See page 19)
D-EJ625 (Canadian MODEL) D-EJ625 (Taiwan MODEL)
Ref. No. Part No. Description Part No. Description
ACCESSORIES & PACKING MATERIALS (Service Manual See page 26, 27)
ELECTRICAL PARTS LIST (Service Manual See page 22 to 26)
* A-3323-654-A MAIN BOARD, COMPLETE A-3021-504-A MAIN BOARD, COMPLETE
R110 1-216-837-11 METAL CHIP 22K 5% 1/16W 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R210 1-216-837-11 METAL CHIP 22K 5% 1/16W 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R807 1-216-851-11 METAL CHIP 330K 5% 1/16W 1-216-845-11 METAL CHIP 100K 5% 1/16W
R813 1-216-839-11 METAL CHIP 33K 5% 1/16W 1-216-847-11 METAL CHIP 150K 5% 1/16W
R818 1-216-847-11 METAL CHIP 150K 5% 1/16W 1-216-843-11 METAL CHIP 68K 5% 1/16W
R826 1-216-849-11 METAL CHIP 220K 5% 1/16W 1-216-841-11 METAL CHIP 47K 5% 1/16W
D-EJ626CK (AEP MODEL) D-EJ626CK (French MODEL)
Ref. No. Part No. Description Part No. Description
1-756-158-31 BATTERY PACK 1-756-158-11 BATTERY PACK (NC-WMAA)
3-225-006-21 MANUAL, INSTRUCTION (ENGLISH) 3-225-007-11 MANUAL, INSTRUCTION(TRADITIONAL CHINESE)
3-225-006-31 MANUAL, INSTRUCTION (FRENCH) 3-225-007-21 MANUAL, INSTRUCTION (ENGLISH)
D-EJ626CK (AEP MODEL) D-EJ626CK (French MODEL)
Ref. No. Part No. Description Part No. Description
3-226-312-31 MANUAL, INSTRUCTION (FRENCH) 3-226-312-31 MANUAL, INSTRUCTION (FRENCH)
3-226-312-41 MANUAL, INSTRUCTION (DUTCH)
3-226-312-51 MANUAL, INSTRUCTION (SWEDISH)
3-226-312-61 MANUAL, INSTRUCTION (PORTUGUES)
3-226-312-71 MANUAL, INSTRUCTION (GERMAN)
3-226-312-81 MANUAL, INSTRUCTION (ITALIAN)
3-226-312-91 MANUAL, INSTRUCTION (FINNISH)
