– 34 –
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
764T LST MAIN
Les composants identifiés par une
marque ! sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
• Abbreviation
AUS : Australian
CH : Chinese
CND : Canadian
EE : East European
E13 : 220 – 230V AC Area
E33 : 100 – 240 V AC Area
E92 : 120 V AC Area
FR : French
HK : Hong Kong
KR : Korean
JEW : Tourist
* 1-669-791-11 764T BOARD
**********
< CAPACITOR >
C591 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
< DIODE >
D591 8-719-988-62 DIODE 1SS355
D592 8-719-941-86 DIODE DAN202U
< TRANSISTOR >
Q591 8-729-231-74 TRANSISTOR 2SC4116-GL
< RESISTOR >
R591 1-216-846-11 METAL CHIP 120K 5% 1/16W
R592 1-216-853-11 METAL CHIP 470K 5% 1/16W
************************************************************
* 1-669-601-11 LST BOARD
**********
< TRANSISTOR >
Q417 8-729-230-60 TRANSISTOR 2SA1586-YG
< RESISTOR >
R422 1-218-891-11 METAL CHIP 68K 0.5% 1/16W
R424 1-216-845-11 METAL CHIP 100K 5% 1/16W
R432 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
************************************************************
A-3306-811-A MAIN BOARD, COMPLETE
(E700/EXCEPT E705: FR)
A-3321-073-A MAIN BOARD, COMPLETE
(E800/EXCEPT E805: FR)
A-3321-207-A MAIN BOARD, COMPLETE (E805: FR)
A-3321-210-A MAIN BOARD, COMPLETE (E705: FR)
*********************
4-993-132-01 TERMINAL BOARD (+), BATTERY
4-993-133-01 TERMINAL BOARD (-), BATTERY
4-993-134-01 PLATE, CHARGE DETECTION
< CAPACITOR >
C101 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C102 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C103 1-115-156-11 CERAMIC CHIP 1uF 10V
C104 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C105 1-113-690-11 ELECT CHIP 220uF 20% 4V
C106 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C107 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C111 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C201 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C202 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C203 1-115-156-11 CERAMIC CHIP 1uF 10V
C204 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C205 1-113-690-11 ELECT CHIP 220uF 20% 4V
C206 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C207 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C211 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C301 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C302 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C303 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C304 1-113-690-11 ELECT CHIP 220uF 20% 4V
C305 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C306 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C307 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C308 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C309 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C310 1-115-156-11 CERAMIC CHIP 1uF 10V
C311 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C312 1-164-346-11 CERAMIC CHIP 1uF 16V
C313 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C314 1-115-156-11 CERAMIC CHIP 1uF 10V
C315 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C317 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C318 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C319 1-115-156-11 CERAMIC CHIP 1uF 10V
C320 1-115-156-11 CERAMIC CHIP 1uF 10V
To Next Page
