– 38 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
R601 1-216-864-11 METAL CHIP 0 5% 1/16W
R602 1-216-833-11 METAL CHIP 10K 5% 1/16W
R603 1-216-833-11 METAL CHIP 10K 5% 1/16W
R604 1-216-833-11 METAL CHIP 10K 5% 1/16W
R612 1-216-821-11 METAL CHIP 1K 5% 1/16W
R801 1-216-821-11 METAL CHIP 1K 5% 1/16W
R802 1-216-833-11 METAL CHIP 10K 5% 1/16W
R803 1-216-821-11 METAL CHIP 1K 5% 1/16W
R804 1-216-854-11 METAL CHIP 560K 5% 1/16W
R805 1-216-861-11 METAL CHIP 2.2M 5% 1/16W
R806 1-216-857-11 METAL CHIP 1M 5% 1/16W
R807 1-216-857-11 METAL CHIP 1M 5% 1/16W
R808 1-216-845-11 METAL CHIP 100K 5% 1/16W
R809 1-216-857-11 METAL CHIP 1M 5% 1/16W
R810 1-216-857-11 METAL CHIP 1M 5% 1/16W
R811 1-216-845-11 METAL CHIP 100K 5% 1/16W
R812 1-216-857-11 METAL CHIP 1M 5% 1/16W
R813 1-216-821-11 METAL CHIP 1K 5% 1/16W
(E800/E805)
R814 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R818 1-216-864-11 METAL CHIP 0 5% 1/16W
R820 1-216-857-11 METAL CHIP 1M 5% 1/16W
R822 1-216-839-11 METAL CHIP 33K 5% 1/16W
R823 1-216-849-11 METAL CHIP 220K 5% 1/16W
R824 1-216-845-11 METAL CHIP 100K 5% 1/16W
(E700/E705)
R824 1-216-864-11 METAL CHIP 0 5% 1/16W
(E800/E805)
R825 1-216-851-11 METAL CHIP 330K 5% 1/16W
R826 1-216-851-11 METAL CHIP 330K 5% 1/16W
R827 1-216-851-11 METAL CHIP 330K 5% 1/16W
R828 1-216-849-11 METAL CHIP 220K 5% 1/16W
R829 1-216-848-11 METAL CHIP 180K 5% 1/16W
R830 1-216-851-11 METAL CHIP 330K 5% 1/16W
R831 1-216-821-11 METAL CHIP 1K 5% 1/16W
(E800/E805)
R835 1-216-821-11 METAL CHIP 1K 5% 1/16W
R836 1-218-740-11 METAL CHIP 100K 0.5% 1/16W
R837 1-218-740-11 METAL CHIP 100K 0.5% 1/16W
R849 1-216-821-11 METAL CHIP 1K 5% 1/16W
R853 1-216-821-11 METAL CHIP 1K 5% 1/16W
R855 1-216-821-11 METAL CHIP 1K 5% 1/16W
R856 1-216-821-11 METAL CHIP 1K 5% 1/16W
R857 1-216-821-11 METAL CHIP 1K 5% 1/16W
R858 1-216-821-11 METAL CHIP 1K 5% 1/16W
(E700/E705)
< VARIABLE RESISTOR >
RV301 1-225-468-21 RES, VAR, CARBON 10K/10K (∑VOL)
RV401 1-241-395-11 RES, ADJ, METAL GLAZE 10K
RV502 1-223-996-21 RES, CARBON ADJ VAR 22K
RV503 1-223-996-21 RES, CARBON ADJ VAR 22K
< SWITCH >
S301 1-762-078-11 SWITCH, SLIDE (AVLS)
S801 1-692-366-31 SWITCH, PUSH (1 KEY) (OPEN)
S803 1-762-078-11 SWITCH, SLIDE (RESUME)
S804 1-762-078-11 SWITCH, SLIDE (HOLDc)
< TRANSFORMER >
T401 1-431-557-11 TRANSFORMER, DC-DC CONVERTER
< VIBRATOR >
X301 1-767-605-11 VIBRATOR, LITHIUM TANTALATE
(16.8935MHz)
X801 1-767-192-11 VIBRATOR, CERAMIC (4.195MHz)
************************************************************
MISCELLANEOUS
***************
6 1-475-340-11 SWITCH UNIT (E700/E705)
15 1-475-341-11 SWITCH UNIT (E800/E805)
104 1-783-093-11 LEAD (WITH CONNECTOR)
109 1-667-512-11 SLIDE FLEXIBLE BOARD
! 110 X-4948-977-1 OPTICAL PICK-UP (DAX-11D)
M901 A-3311-902-A MOTOR ASSY, SLED
M902 A-3311-901-A MOTOR ASSY, TURN TABLE
S901 1-571-099-21 SWITCH (1 KEY)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
! 1-467-007-21 ADAPTOR, AC (AC-E455) (AUS)
! 1-467-195-11 ADAPTOR, AC (AC-E455A) (US, CND, E92)
! 1-467-550-11 ADAPTOR, AC (AC-E455A) (E33, JEW)
! 1-473-115-11 ADAPTOR, AC (AC-E455D) (UK)
! 1-473-116-31 ADAPTOR, AC (AC-E455D) (E705: AEP, FR,
EE ,E13 , CH/E805: AEP, FR, E13, CH)
1-475-394-11 CONTROL UNIT, REMOTE(RM-DM27L)
(E705, CND)
1-475-395-11 REMOTE COMTROL UNIT(RM-DM28EL)
(E705: EXCEPT US, CND/E805:
CND, UK, E, FR, HK, KR)
1-475-603-11 REMOTE COMMANDER (RM-DM29) (E805: US)
1-475-623-11 ADAPTOR, AC (AC-E455) (HK)
! 1-569-007-11 ADAPTOR, CONVERSION 2P (E33, JEW)
! 1-569-008-11 ADAPTOR, CONVERSION 2P (E13, CH)
1-751-419-11 CORD, CONNECTION
(US, CND, E, HK, KR, AUS, CH)
3-860-135-02 MANUAL, INSTRUCTION (JAPANESE, ENGLISH)
(JEW)
3-860-135-11 MANUAL, INSTRUCTION (SPANISH)
(AEP, E33, E92, JEW)
3-860-135-21 MANUAL, INSTRUCTION (ENGLISH)
(EXCEPT E13, HK, KR, CH)
3-860-135-31 MANUAL, INSTRUCTION (FRENCH)
(CND, AEP, FR, JEW)
3-860-135-41 MANUAL, INSTRUCTION (DUTCH)
(E705: AEP, EE/E805: AEP)
3-860-135-51 MANUAL, INSTRUCTION (SWEDISH) (AEP)
3-860-135-61 MANUAL, INSTRUCTION (PORTUGUESE)(AEP)
3-860-135-71 MANUAL, INSTRUCTION (GERMAN) (AEP)
3-860-135-81 MANUAL, INSTRUCTION (ITALIAN) (AEP)
3-860-135-91 MANUAL, INSTRUCTION (CHINESE) (JEW)
3-861-194-11 MANUAL, INSTRUCTION (KOREAN) (KR, JEW)
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
