– 70 –
D-V8000
Ref. No. Part No. Description Remark
* 1-669-608-11 SUB BOARD
**********
< IC >
IC1 8-759-530-69 IC XC61A4502
< TRANSISTOR >
Q1 8-729-907-00 TRANSISTOR DTC114EUA-T106
< RESISTOR >
R1 1-216-809-11 METAL CHIP 100 5% 1/16W
R3 1-216-809-11 METAL CHIP 100 5% 1/16W
MISCELLANEOUS
***************
56 1-475-520-11 LIGHT UNIT, BACK
57 1-694-374-11 CONDUCTIVE BOARD, CONNECTION
61 1-776-149-11 FLEXIBLE FLAT CABLE
! 102 8-848-295-51 OPTICAL PICK-UP KSS-331C
103 1-948-418-21 HARNESS
LCD401 1-801-975-11 DISPLAY PANEL, LIQUID CRYSTAL
M901 X-2625-485-1 MOTOR ASSY (MS), T.T. (SPINDLE)
M902 X-2625-171-2 MOTOR ASSY, SLED
S910 1-570-771-11 SWITCH (LIMIT)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-105-19 SCREW (2X8), TAPPING (B)
#2 7-627-852-17 +P 1.7X4
#3 7-627-852-18 SCREW, PRECISION +P 1.7X4 TYPE3
#4 7-685-104-19 SCREW (2X6), TAPPING (B)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
! 1-467-570-31 ADAPTOR, AC (AC-E60HG) (E)
! 1-475-609-11 ADAPTOR, AC (AC-E67) (Chinese)
1-783-028-11 CORD (WITH PLUG) (AV MONITOR CORD)
3-861-942-11 MANUAL, INSTRUCTION (ENGLISH,CHINESE)
3-861-942-21 MANUAL, INSTRUCTION
(JAPANESE, KOREAN) (Tourist)
4-991-047-01 LID, BATTERY CASE (for RM-DV8000)
8-917-618-90 REMOTE COMMADER RM-DV8000
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
Sony Corporation
Personal A&V Products Company
97K057015-1
Printed in Singapore © 1997. 11
Published by Quality Engineering Dept.
(Shibaura)
9-923-278-11
