– 25 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R824 1-216-801-11 METAL CHIP 22 5% 1/16W
R826 1-216-857-11 METAL CHIP 1M 5% 1/16W
R827 1-218-877-11 RES, CHIP 18K 0.50% 1/16W
R828 1-218-879-11 RES, CHIP 22K 0.50% 1/16W
R860 1-218-883-11 RES, CHIP 33K 0.50% 1/16W
R861 1-218-887-11 RES, CHIP 47K 0.50% 1/16W
R862 1-218-885-11 RES, CHIP 39K 0.50% 1/16W
R863 1-218-885-11 RES, CHIP 39K 0.50% 1/16W
R864 1-218-883-11 RES, CHIP 33K 0.50% 1/16W
R865 1-218-887-11 RES, CHIP 47K 0.50% 1/16W
R866 1-218-885-11 RES, CHIP 39K 0.50% 1/16W
R867 1-218-885-11 RES, CHIP 39K 0.50% 1/16W
R869 1-216-833-11 METAL CHIP 10K 5% 1/16W
R870 1-218-878-11 RES, CHIP 20K 0.50% 1/16W
R871 1-216-833-11 METAL CHIP 10K 5% 1/16W
R872 1-216-833-11 METAL CHIP 10K 5% 1/16W
R873 1-218-871-11 RES, CHIP 10K 0.50% 1/16W
R874 1-218-847-11 RES, CHIP 1K 0.50% 1/16W
R880 1-216-801-11 METAL CHIP 22 5% 1/16W
R881 1-216-857-11 METAL CHIP 1M 5% 1/16W
R882 1-218-907-11 RES, CHIP 330K 0.50% 1/16W
R883 1-218-882-11 RES, CHIP 30K 0.50% 1/16W
R884 1-218-877-11 RES, CHIP 18K 0.50% 1/16W
R885 1-216-857-11 METAL CHIP 1M 5% 1/16W
R886 1-216-809-11 METAL CHIP 100 5% 1/16W
R888 1-216-295-00 SHORT 0
R892 1-216-857-11 METAL CHIP 1M 5% 1/16W
R896 1-218-883-11 RES, CHIP 33K 0.50% 1/16W
R897 1-218-869-11 RES, CHIP 8.2K 0.50% 1/16W
R901 1-216-833-11 METAL CHIP 10K 5% 1/16W
R904 1-216-845-11 METAL CHIP 100K 5% 1/16W
R921 1-218-887-11 RES, CHIP 47K 0.50% 1/16W
R922 1-218-883-11 RES, CHIP 33K 0.50% 1/16W
R924 1-216-857-11 METAL CHIP 1M 5% 1/16W
R926 1-216-845-11 METAL CHIP 100K 5% 1/16W
R927 1-216-845-11 METAL CHIP 100K 5% 1/16W
R960 1-216-809-11 METAL CHIP 100 5% 1/16W
R961 1-216-022-00 METAL CHIP 75 5% 1/10W
R962 1-216-833-11 METAL CHIP 10K 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-225-570-11 RES, VAR, CARBON 10K/10K (VOLUME)
< SWITCH >
S701 1-572-922-11 SWITCH, SLIDE (HOLD)
S702 1-572-922-11 SWITCH, SLIDE (RESUME)
S703 1-692-605-31 SWITCH, SLIDE
(PAL, AUTO, NTSC (VIDEO SYSTEM))
< TRANSFORMER >
T891 1-431-652-21 TRANSFORMER, DC-DC CONVERTER
< VIBRATOR >
X320 1-767-366-21 VIBRATOR, CERAMIC (16.934MHz)
X701 1-579-063-41 VIBRATOR, CERAMIC (4.19MHz)
X920 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
************************************************************
MISCELLANEOUS
**************
61 1-776-149-11 FLEXIBLE FLAT CABLE
104 1-690-530-81 LEAD (WITH CONNECTOR)
109 1-660-965-11 SLIDE FLEXIBLE BOARD
! 110 X-4950-060-1 OPTICAL PICK-UP (DAX-01A2)
M901 A-3303-458-A MOTOR ASSY, TURNTABLE (SPINDLE)
M902 A-3303-403-A MOTOR ASSY, SLED
S910 1-571-099-21 SWITCH (1 KEY) (LIMIT)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
! 1-467-570-31 ADAPTOR, AC (AC-E60HG) (E)
! 1-475-712-11 ADAPTOR, AC (AC-E67A) (Chinese)
1-783-028-11 CORD (WITH PLUG) (AV MONITOR CORD)
3-861-942-11 MANUAL, INSTRUCTION (ENGLISH,CHINESE)
3-861-942-21 MANUAL, INSTRUCTION
(JAPANESE, KOREAN) (Tourist)
4-991-047-01 LID, BATTERY CASE (for RM-DV10)
8-917-658-90 REMOTE COMMADER RM-DV10
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
MAIN
(New Type)
