12 Main camera lens
13 Camera light
14 GPS antenna area
15 Wi-Fi/Bluetooth antenna area
16 Cover for charger/USB cable port
17 NFC™ detection area
18 Charging dock connector
19 Strap hole
Assembly
Your device only supports nano SIM cards.
Make sure you insert the nano SIM card into the nano SIM card holder before inserting it into
the device. Also, don’t confuse the nano SIM card slot with the memory card slot.
7
