3 Second microphone
4 Proximity/Light sensor
5 Ear speaker/Second speaker
6 Front camera lens
7 Nano SIM card slot cover
8 Power key
9 Volume/Zoom key
10 Camera key
11 Main microphone/Speaker
12 Wi-Fi/Bluetooth antenna area
13 Main camera lens
14 Camera light
15 GPS antenna area
16 Cover for charger/USB port and memory card slot
17 NFC™ detection area
18 Charging dock connector
19 Strap hole
NFC payments are only supported when an NFC-enabled SIM card is inserted in the lower
SIM card slot, which is indicated by the number "1." Make sure you position the NFC-enabled
SIM card properly in the holder before you insert the holder into the slot.
Assembly
Your device only supports nano SIM cards.
