Sony DAV-SC5 - Specifications

Additional Information
73
GB
Amplifier section
Stereo mode 90 W + 90 W (4 ohms at
1 kHz, THD 10 %)
Surround mode Front: 90 W + 90 W
Centre*:
90 W
Surround*:
90 W + 90W
(4 ohms at 1 kHz, THD
10 %)
Subwoofer*:
100 W
(4 ohms at 100 Hz, THD
10 %)
* Depending on the sound field settings and the source,
there may be no sound output.
Inputs VIDEO 1:
Sensitivity: 150 mV
Impedance: 50 kilohms
VIDEO 2:
Sensitivity: 300 mV
Impedance: 50 kilohms
Outputs VIDEO 1 (AUDIO
OUT):
Voltage: 1 V
Impedance: 1 kilohm
Phones Accepts low-and high-
impedance headphones.
Super Audio CD/DVD system
Laser Semiconductor laser
(Super Audio CD/DVD: λ
= 650 nm)
(CD: λ = 780 nm)
Emission duration:
continuous
Signal format system NTSC or NTSC/PAL
Frequency response (at 2 CH STEREO mode)
DVD (PCM): 2 Hz to 22
kHz (±1.0 dB)
CD: 2 Hz to 20 kHz (±1.0
dB)
Harmonic distortion Less than 0.03 %
Tuner section
System PLL quartz-locked digital
synthesizer system
FM tuner section
Tuning range 87.5 – 108.0 MHz
(50 kHz step)
Aerial FM wire aerial
Aerial terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range
Middle Easten models: 531 – 1,602 kHz (with the
interval set at 9 kHz)
Other models: 531 – 1,602 kHz (with the
interval set at 9 kHz)
530 – 1,710 kHz (with the
interval set at 10 kHz)
Aerial AM loop aerial
Intermediate frequency 450 kHz
Video section
Inputs Video: 1 Vp-p 75 ohms
Outputs Video: 1 Vp-p 75 ohms
S video:
Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms
COMPONENT:
Y: 1 Vp-p 75 ohms
PB/CB, PR/CR: 0.7 Vp-p
75 ohms
Speakers
Front/Surround
Speaker system Bass reflex
Speaker unit 70 mm dia. cone type
Rated impedance 4 ohms
Dimensions (approx.) 128 × 216 × 114 mm
(w/h/d, with the stand)
Mass (approx.) 0.53 kg
Centre
Speaker system Bass reflex
Speaker unit 70 mm dia. cone type
Rated impedance 4 ohms
Dimensions (approx.) 190 × 122 × 89 mm
(w/h/d, with the stand)
Mass (approx.) 0.56 kg
Specifications
continued
