Sony DCR-IP1 - Page 9

1-5E
DCR-IP1/IP1E
E
E
E
E
Block
Function
61
61
62
62
Detailed
Code
00
10
00
01
Symptom/State
Difficult to adjust focus
(Cannot initialize focus.)
Zoom operations fault
(Cannot initialize zoom lens.)
Steadyshot function does not work well.
(With pitch angular velocity sensor output
stopped.)
Steadyshot function does not work well.
(With yaw angular velocity sensor output
stopped.)
Self-diagnosis Code
Repaired by:
Correction
Inspect the lens block focus MR sensor (Pins qk, ql of CN5001 of
CD-458 board) when focusing is performed when the touch panel
is operated in the focus manual mode and the focus motor drive
signals (Pins 1, 2 of CN5001 of CD-458 board) when the focusing
is not performed.
Inspect the lens block zoom reset sensor (Pin qg of CN5001 of
CD-458 board) when zooming is performed when the zoom switch
is operated and the zoom motor drive signals (Pins wf to wj of
CN5001 of CD-458 board) when zooming is not performed.
Inspect pitch angular velocity sensor (SE2702 of SE-139 board)
peripheral circuits.
Inspect yaw angular velocity sensor (SE2701 of SE-139 board)
peripheral circuits.
