Sony DCR-PC7 - Page 10

2-7
CD-159
(CCD Imager • Steady Shot Sensor)
PD-71
(RGB Decoder)
MR-36
(REC/PB Amp, Servo
)
DD-91
(Power)
VF-106
(Color EVF)
VC-183
Camera, IN/OUT, Blocking, ECC • TBC • CHCD, Audio Processor,
Clock Synchronize Processor, DV IN/OUT, Mode Control, Audio,
Audio Control
CC-97
(Connector
)
2-11. CIRCUIT BOARDS LOCATION
E
