– 31 –
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
AR : Argentine G : German
AUS : Australian CND : Canadian
FR : French HK : Hong Kong
EA : Saudi Arabia CN : Chinese
EE : East European
AEP : Manual of English is attached
7AEP : Manual of 9 language is attached
C&SA : Central and South America
E13 : AC220-230V area model
E33 : AC100-240V area model
Les composants identifiés par une
marque ! sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board.
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number specified.
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
A-3323-101-A MAIN BOARD,COMPLETE (FR)
*********************
A-3323-102-A MAIN BOARD,COMPLETE (EXCEPT FR)
********************
4-213-876-01 HOLDER(LCD)
4-978-695-01 PLATE,TERMINAL, BATTERY
< CAPACITOR >
C101 1-126-794-11 ELECT 4.7uF 20% 50V
C102 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C103 1-115-156-11 CERAMIC CHIP 1uF 10V
C104 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C105 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C106 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C108 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C201 1-126-794-11 ELECT 4.7uF 20% 50V
C202 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C203 1-115-156-11 CERAMIC CHIP 1uF 10V
C204 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C205 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C206 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C208 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C302 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C303 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C304 1-124-635-00 ELECT 220uF 20% 6.3V
C305 1-124-584-00 ELECT 100uF 20% 10V
C306 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C307 1-126-795-11 ELECT 10uF 20% 25V
C308 1-126-795-11 ELECT 10uF 20% 25V
C312 1-128-057-11 ELECT 330uF 20% 6.3V
C313 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C314 1-115-156-11 CERAMIC CHIP 1uF 10V
C315 1-126-514-11 ELECT 22uF 20% 10V
C316 1-216-864-11 METAL CHIP 0 5% 1/16W
C317 1-115-156-11 CERAMIC CHIP 1uF 10V
C323 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C324 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C326 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C335 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C402 1-126-785-11 ELECT 47uF 20% 10V
C403 1-127-485-00 ELECT 33uF 20% 6.3V
C404 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C405 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C406 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C407 1-115-156-11 CERAMIC CHIP 1uF 10V
C408 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C410 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C411 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C414 1-115-156-11 CERAMIC CHIP 1uF 10V
C415 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C417 1-104-852-11 TANTAL. CHIP 22uF 20% 6.3V
C420 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C421 1-124-635-00 ELECT 220uF 20% 6.3V
C424 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C425 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C426 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C427 1-104-852-11 TANTAL. CHIP 22uF 20% 6.3V
C428 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C432 1-115-156-11 CERAMIC CHIP 1uF 10V
C437 1-115-156-11 CERAMIC CHIP 1uF 10V
C439 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C501 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C503 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C504 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C505 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C506 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C509 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C510 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C511 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C512 1-115-156-11 CERAMIC CHIP 1uF 10V
C513 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C514 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C515 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C516 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C517 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C518 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C519 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
