Sony DRU-830A - Installing as a Second Drive

16
Connect the drive as follows.
Installing the DVD/CD rewritable drive as a second drive
Secondary
IDE connector
Primary
IDE connector
2nd drive
Place the jumper in
the MASTER position.
DVD/CD
rewritable drive
1st drive
Hard disk drive (usually)
MASTER
The following configuration is also possible.
Secondary
IDE connector
Primary
IDE connector
Place the jumper
in the SLAVE
position.
DVD/CD
rewritable drive
1st drive
Hard disk drive (usually)
MASTER
2nd drive
