Sony DRU-830A - Installing as a Fourth Drive

18
Connect the drive as follows.
Installing the DVD/CD rewritable drive as a fourth drive
Secondary
IDE connector
Primary
IDE connector
Place the jumper in
the SLAVE position.
DVD/CD
rewritable drive
1st drive
Hard disk drive (usually)
MASTER
4th drive
2nd drive
Hard disk drive, or
DVD/CD drive, etc.
SLAVE
3nd drive
Hard disk drive, or
DVD/CD drive, etc.
MASTER
