5-10
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-H10_L2
• Refer to page 5-1 for mark 0.
< CONNECTOR >
* CN001 1-816-654-51 FFC/FPC CONNECTOR (LIF) 6P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D002 6-500-776-01 DIODE MAZW068H0LS0
* D003 6-501-524-01 DIODE DOR5099
(SELF-TIMER/AF ILLUMINATOR)
< RELAY >
* RY001 1-455-056-11 SOLENOID, PLUNGER (STROBE OPEN)
************************************************************
A-1441-938-A ST-193 FLEXIBLE BOARD, COMPLETE
******************************
(S101 (MODE DIAL) is not supplied, but this is included in ST-193 flexible
complete board.)
< LITHIUM RECHARGEABLE BATTERY >
0 BT001 1-756-711-11 LITHIUM RECHARGEABLE BATTERY
< CAPACITOR >
C001 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C003 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C004 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
0*C006 1-114-476-11 ELECT 183uF 99% 315V
< CONNECTOR >
* CN001 1-818-087-51 CONNECTOR, FFC/FPC (LIF) 26P
< DIODE >
D001 6-500-619-01 DIODE RB520S-40TE61 (POWER)
0 D002 6-501-141-01 DIODE FT02P80TP
D101 6-501-030-01 DIODE SML-412MWT86
< IC >
IC001 6-707-555-01 IC TPS65552RGTR
< COIL >
L001 1-456-499-11 INDUCTOR 4.7uH
< TRANSISTOR >
0*Q001 6-551-686-01 TRANSISTOR TIG030TS-S-TL-E
< RESISTOR >
R001 1-216-864-11 SHORT CHIP 0
R002 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R003 1-218-989-11 RES-CHIP 1M 5% 1/16W
R004 1-218-940-11 RES-CHIP 82 5% 1/16W
R005 1-218-935-11 RES-CHIP 33 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB101 1-234-376-11 RES, NETWORK 2.2K (1005X4)
RB102 1-234-376-11 RES, NETWORK 2.2K (1005X4)
< SWITCH >
S101 (Not supplied) SWITCH, ROTARY (MODE DIAL)
S102 1-786-819-22 TACTILE SWITCH (SHUTTER)
* S103 1-786-914-31 SWITCH, TACTILE (POWER)
< TRANSFORMER >
0 T001 1-445-108-21 TRANSFORMER, D.C-D.C CONVERTER
************************************************************
A-1441-936-A SW-530 BOARD, COMPLETE
***********************
< CONNECTOR >
* CN001 1-816-654-51 FFC/FPC CONNECTOR (LIF) 6P
< RESISTOR >
R001 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB001 1-234-376-11 RES, NETWORK 2.2K (1005X4)
RB002 1-234-376-11 RES, NETWORK 2.2K (1005X4)
< SWITCH >
S001 1-786-819-22 TACTILE SWITCH (W/INDEX)
S002 1-786-819-22 TACTILE SWITCH (T)
* S003 1-786-914-31 SWITCH, TACTILE (MENU)
* S004 1-786-914-31 SWITCH, TACTILE (HOME)
* S005 1-786-914-31 SWITCH, TACTILE (LEFT/MACRO)
* S006 1-786-914-31 SWITCH, TACTILE (UP/DISP)
* S007 1-786-914-31 SWITCH, TACTILE (SET)
* S008 1-786-914-31 SWITCH, TACTILE (DOWN/SELF-TIMER)
* S009 1-786-914-31 SWITCH, TACTILE (RIGHT/FLASH)
************************************************************
Electrical parts list of the SY-210 board is
not shown.
Pages 5-11 to 5-14 are not shown.
SW-530ST-193PL-048
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
注意
電池の交換は，正しく行わないと破裂する恐れがあり
ます。電池を交換する場合には必ず同じ型名の電池
又は同等品と交換してください。
To Next Page
