GB
8
A Shutter button
B Mode dial
C For shooting: W/T (zoom) lever
For viewing: (Playback
zoom) lever/ (Index) lever
D Flash
E ON/OFF (Power) button/Power
lamp
F Microphone
G Self-timer lamp/Smile Shutter
lamp/AF illuminator
H Lens
I (TransferJet™) mark
J LCD screen
K (Playback) button
L Hook for wrist strap
M / (In-Camera Guide/Delete)
button
N MENU button
O Control button
Menu on: v/V/b/B/z
Menu off: DISP/ / / /
Tracking focus
P Speaker
Q Tripod receptacle
• Use a tripod with a screw less
than 5.5 mm (7/32 inches) long.
Otherwise, you cannot firmly
secure the camera, and damage to
the camera may occur.
R Multi connector (Type3a)
S Battery/Memory card cover
T Battery insertion slot
U Battery eject lever
V Memory card slot
W Access lamp
Identifying parts
