Ref. No. Part No. Description Ref. No. Part No. Description
5-9
DSC-S60/S80/S90/ST80
A-1119-576-A SY-126 BOARD, COMPLETE (SERVICE) (GP2)
(S60: US, CND, AUS/S80: AUS/ST80: Vietnam/
S90: US, CND, AUS)
A-1119-577-A SY-126 BOARD, COMPLETE (SERVICE) (GP3)
(AEP, UK)
A-1119-578-A SY-126 BOARD, COMPLETE (SERVICE) (GP4)
(S60: E/S80: E/ST80: E/S90: AR, E)
A-1119-579-A SY-126 BOARD, COMPLETE (SERVICE) (GP5)
(S60: CH, HK, KR, JE/S80: HK, KR/ST80: HK/
S90: CH, HK, KR, JE)
***********************
(This complete board is including
CP401 (CH-169 board).)
CP401 A-1106-355-A CH-169 BOARD, COMPLETE
< CAPACITOR >
C003 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C004 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C005 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C006 1-109-994-11 CERAMIC CHIP 2.2uF 10% 10V
C007 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C008 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C009 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C010 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
C011 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
C012 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C013 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C014 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C015 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C016 1-100-881-91 CERAMIC CHIP 47uF 20% 6.3V
C017 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C019 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C020 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C021 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C023 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C024 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C025 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C027 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C028 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C029 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C031 1-100-671-11 CERAMIC CHIP 4.7uF 20% 25V
C033 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C034 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C035 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C038 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C040 1-100-670-11 CERAMIC CHIP 4.7uF 20% 16V
C044 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C045 1-100-670-11 CERAMIC CHIP 4.7uF 20% 16V
C046 1-100-670-11 CERAMIC CHIP 4.7uF 20% 16V
C047 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C048 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C049 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C050 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C101 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C105 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C106 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C107 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C108 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C110 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C111 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C112 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C114 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C115 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C116 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C117 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C118 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C119 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C122 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C123 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C126 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C127 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C128 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C129 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C130 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C131 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C133 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C134 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C135 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C136 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C137 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C138 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C142 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C143 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C146 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C147 1-100-786-91 TANTAL. CHIP 22uF 20% 6.3V
C148 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
C205 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C206 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C207 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C208 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C209 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C210 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C211 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C212 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C213 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C214 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C215 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C301 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C302 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C401 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C402 1-137-988-91 CERAMIC CHIP 1uF 10% 35V
C403 1-113-992-11 TANTAL. CHIP 3.3uF 20% 35V
C404 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C405 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C406 1-113-992-11 TANTAL. CHIP 3.3uF 20% 35V
C408 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C409 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C410 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C502 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C504 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C506 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C507 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C508 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C510 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C511 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C512 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C513 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C514 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C515 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C516 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C517 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
SY-126
