Sony DSC-S60 Service Manual

Ref. No. Part No. Description Ref. No. Part No. Description
5-10
DSC-S60/S80/S90/ST80
SY-126
C521 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C601 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C602 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C603 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C604 1-112-662-91 TANTAL. CHIP 47uF 20% 10V
C702 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
< CONNECTOR >
CN001 1-580-057-11 PIN, CONNECTOR (SMD) 4P
CN401 1-784-423-21 FFC/CONNECTOR, FPC (ZIF) 39P
CN601 1-784-421-11 FFC/CONNECTOR, FPC (ZIF) 27P
CN701 1-817-623-41 CONNECTOR, FPC (ZIF) 45P
CN702 1-817-705-11 CONNECTOR, FPC (LIF (NON-ZIF)) 10P
CN703 1-794-375-21 PIN, CONNECTOR 2P
CN704 1-816-645-31 FFC/FPC CONNECTOR (LIF) 14P
CN705 1-816-646-31 FFC/FPC CONNECTOR (LIF) 16P
CN706 1-815-333-11 CONNECTOR, FPC (ZIF) 33P
< DIODE >
D001 8-719-069-29 DIODE RB520S-30TE61
D002 8-719-069-29 DIODE RB520S-30TE61
D003 8-719-069-29 DIODE RB520S-30TE61
D004 8-719-158-49 DIODE RD12SB2
D401 8-719-056-23 DIODE MA2S111-(K8).SO
< FUSE >
0 F001 1-576-851-21 FUSE (2A/32V)
0 F002 1-576-851-21 FUSE (2A/32V)
0 F003 1-576-570-11 FUSE, MICRO (1608 TYPE) (0.63A/32V)
< FERRITE BEAD >
FB105 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB106 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB107 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB108 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB109 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB201 1-414-921-11 INDUCTOR, FERRITE BEAD
FB202 1-414-921-11 INDUCTOR, FERRITE BEAD
FB401 1-469-082-21 INDUCTOR, FERRITE BEAD (1005)
FB402 1-469-082-21 INDUCTOR, FERRITE BEAD (1005)
FB403 1-469-082-21 INDUCTOR, FERRITE BEAD (1005)
FB404 1-400-723-11 INDUCTOR, FERRITE BEAD (1005)
FB405 1-400-723-11 INDUCTOR, FERRITE BEAD (1005)
FB406 1-400-723-11 INDUCTOR, FERRITE BEAD (1005)
FB407 1-400-723-11 INDUCTOR, FERRITE BEAD (1005)
FB408 1-400-723-11 INDUCTOR, FERRITE BEAD (1005)
FB701 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB702 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB703 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB704 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB705 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB706 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB707 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB708 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB709 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
< LINE FILTER >
FL201 1-400-648-11 FILTER, CHIP EMI (1606)
FL401 1-400-648-11 FILTER, CHIP EMI (1606)
< IC >
IC001 6-707-916-01 IC SC901570VOR2
IC002 6-700-711-01 IC BA3986FV-E2
IC101 8-753-239-53 IC CXD3188BGG-T6
IC103 6-704-365-01 IC NJM2578KJ1 (TE3)
IC201 (Not supplied) IC S99-50031-01-ER
IC203 6-706-186-01 IC K4S283233F-HN1HT
IC301 6-707-041-01 IC HN29V256A0BBP-30
IC502 6-707-336-01 IC BH6414GLU-E2
IC503 6-702-281-01 IC R1141Q281B-TR-FA
IC601 6-706-005-01 IC BD6756GLV-E2
< COIL >
L001 1-469-967-21 INDUCTOR 10uH
L003 1-456-499-11 INDUCTOR 4.7uH
L004 1-456-499-11 INDUCTOR 4.7uH
L005 1-456-499-11 INDUCTOR 4.7uH
L006 1-457-066-21 COIL, CHOKE 4.7uH
L008 1-456-499-11 INDUCTOR 4.7uH
L009 1-457-066-21 COIL, CHOKE 4.7uH
L010 1-469-553-21 INDUCTOR 4.7uH
L101 1-469-967-21 INDUCTOR 10uH
L102 1-469-757-21 INDUCTOR 10uH
L104 1-469-757-21 INDUCTOR 10uH
L201 1-400-677-11 INDUCTOR 47uH
L401 1-469-561-21 INDUCTOR 100uH
L402 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L403 1-469-967-21 INDUCTOR 10uH
L404 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
< TRANSISTOR >
Q001 8-729-056-01 TRANSISTOR MCH3405-TL-E
Q002 6-550-351-01 TRANSISTOR CPH5812-S-TL-E
Q003 8-729-055-89 TRANSISTOR MCH3306-TL-E
Q004 8-729-053-76 TRANSISTOR CPH5802-TL-E
Q007 8-729-047-68 TRANSISTOR SSM3K03FE (TPL3)
Q008 6-550-844-01 TRANSISTOR FDW2508P/GNL
Q101 6-550-119-01 TRANSISTOR DTC144EMT2L
Q401 8-729-037-74 TRANSISTOR UN9213J-(TX).SO
Q601 8-729-053-29 TRANSISTOR DTA143TMT2L
Q703 8-729-047-68 TRANSISTOR SSM3K03FE (TPL3)
< RESISTOR >
R001 1-218-935-11 RES-CHIP 33 5% 1/16W
R002 1-218-949-11 RES-CHIP 470 5% 1/16W
R003 1-218-965-11 RES-CHIP 10K 5% 1/16W
R004 1-218-975-11 RES-CHIP 68K 5% 1/16W
R005 1-219-570-11 METAL CHIP 10M 5% 1/10W
R006 1-218-990-11 SHORT CHIP 0
R012 1-218-990-11 SHORT CHIP 0
R013 1-208-635-11 METAL CHIP 10 0.5% 1/16W
R014 1-218-969-11 RES-CHIP 22K 5% 1/16W
R016 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R018 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R020 1-218-989-11 RES-CHIP 1M 5% 1/16W
R023 1-218-985-11 RES-CHIP 470K 5% 1/16W
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
