DSC-S950
HELP
HELP
Sheet attachment positions and procedures of processing the flexible boards/harnesses are shown.
HELP01
Be careful about the Lens Assy
Be careful of the weld
Keep clean these Pins.
Don't press the Barrier part.
Don't press the Sensor holder
Don't press the AF motor
HELP02
