5-7
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-T70/T75_L2
A-1334-225-A MC-185 FLEXIBLE BOARD, COMPLETE
*******************************
(CN001 (MULTI CONNECTOR) is not supplied,
but this is included in MC-185 flexible complete board.)
< CONNECTOR >
CN001 (Not supplied) CONNECTOR, MULTIPLE (SOCKET)
(MULTI CONNECTOR)
************************************************************
A-1334-226-A ST-172 FLEXIBLE BOARD, COMPLETE
******************************
0 1-480-416-11 FLASH UNIT (FL60570)
< LITHIUM BATTERY SECONDARY >
*0BT001 1-756-566-11 BATTERY, LITHIUM SECONDARY
< CAPACITOR >
C001 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C002 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
* C004 1-112-832-21 CERAMIC CHIP 0.033uF 10% 250V
C007 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
*0C901 1-114-572-11 CAP, ELECT 21.9uF 315V
*0C902 1-114-572-11 CAP, ELECT 21.9uF 315V
< DIODE >
0 D001 6-501-141-01 DIODE FT02P80TP
* D002 6-501-364-01 DIODE DOR5352
(AF illuminator/self-timer lamp)
D003 6-500-619-01 DIODE RB520S-40TE61
< IC >
IC001 6-707-555-01 IC TPS65552RGTR
< COIL >
* L001 1-400-820-11 INDUCTOR 2.2uH
< TRANSISTOR >
*0Q001 6-551-686-01 TRANSISTOR TIG030TS-S-TL-E
< RESISTOR >
R002 1-218-989-11 RES-CHIP 1M 5% 1/16W
R003 1-218-941-11 RES-CHIP 100 5% 1/16W
R004 1-216-121-00 RES-CHIP 1M 5% 1/10W
R007 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R008 1-218-935-11 RES-CHIP 33 5% 1/16W
< SPEAKER >
* SP901 1-826-759-11 BUZZER, PIEZOELECTRIC (2.0CM)
< TRANSFORMER >
0 T001 1-445-108-21 TRANSFORMER, D.C-D.C CONVERTER
************************************************************
Electrical parts list of the SY-183 board is
not shown.
Pages 5-8 to 5-11 are not shown.
ST-172
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
• Refer to page 5-1 for mark 0.
MC-185
