Sony DSC-W370 - LCD Section Disassembly; LCD Module and Bracket Removal

DSC-W370
2-4
2-1-2. LCD SECTION
1. Removetonumericalorder(5 to 7)intheleftfigure.
DISASSEMBLY
Ref. No. Part No. Description
Ref. No. Part No. Description
* 51 4-179-236-01 LCD BRACKET
52 4-179-233-01 SW BOARD
53 X-2547-198-1 MODE DIAL ASSY
54 4-179-237-01 LCD MODULE
* 55 4-179-235-01 TRIPOD SCREW
#S3 4-179-231-01 MACHINE_M1.4_2_SVR_AB
#S4 4-179-232-01 TAPPING_M1.4_3.5_SVR_AB
5 #S3 X 1
6 LCD Module Raise (6) → #S4 X 3
Back View
#S3
Back View
#S4 LCD Module
6
5�52
53
7�54
6�51
55
#S3
#S4
#S3
Main Frame Section
(See Page 2-5)
