Sony DSR-PD170 - Recording a Picture; Monitoring the Playback Picture on the LCD Screen

Quick Start Guide
4 Press START/
STOP. Your
camcorder starts
recording. To stop
recording, press
START/STOP
again.
Recording a picture
Monitoring the
playback picture on the LCD
screen
1 Set the POWER switch to
VCR while pressing the
small green button.
2 Press m to rewind
the tape.
3 Press N to start
playback.
NOTE
Do not pick up your camcorder by
holding the viewfinder, the LCD panel,
the battery pack, or the microphone.
POWER
OFF
(CHG)
CAMERA
MEMORY
VCR
POWER
OFF
(CHG)
CAMERA
MEMORY
VCR
REW
PLAY
POWER
OFF
(CHG)
CAMERA
MEMORY
VCR
1 Open the shutter of the
hood with a lens cap.
For more information
about attaching the
hood with a lens cap.
2 Set the POWER switch to
CAMERA while pressing
the small green button.
If the ND1 or ND2
indicator flashes.
3 Slide OPEN
back in the B
mark direction
to open the
LCD panel.
OPEN
Viewfinder
When the LCD panel is closed, use the
viewfinder placing your eye against its eyecup.
<<3>>
