Installation
Before installing the unit, remove the protection
collar  and the bracket  from the unit.
1 Pinch both edges of the protection collar
, then pull it out.
2 Insert both release keys  until they
click, and pull down the bracket , then
pull up the unit to separate.
Before installing, make sure the catches on both
sides of the bracket  are bent inwards 2 mm (
3
/32
in). When mounting in a Japanese car, see
“Mounting the unit in a Japanese car” (page 36).
1 Position the bracket  inside the
dashboard, then bend the claws outward
for a tight fit.
2 Mount the unit onto the bracket , then
attach the protection collar .
Notes
 If the catches are straight or bent outwards, the unit
will not be installed securely and may spring out.
 Make sure the 4 catches on the protection collar 
are properly engaged in the slots of the unit.
Removing the protection collar and the
bracket




Face the hook inwards.
Mounting the unit in the dashboard

182 mm (7
1
/4 in)
53 mm (2
1
/8 in)
Catch


