Sony DSX-A410BT Service Manual

40
DSX-A410BT/A415BT
SECTION 7
ELECTRICAL PARTS LIST
KEY BOARD
**********
When the KEY board is defective, replace the front panel assy (Ref. No. FP1).
*************************************************************
A-2186-920-A MAIN BOARD, COMPLETE (A415BT) (See Note 1)
A-2186-921-A MAIN BOARD, COMPLETE (A410BT) (See Note 1)
********************
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
7-685-794-01 SCREW +PTT 2.6X10 (S)
< ANTENNA >
ANT001 (Not supplied) ANTENNA (CHIP MULTILYAER) (BT ANTENNA)
(See Note 2)
< CAPACITOR >
C2 1-116-153-11 CERAMIC CHIP 18PF 1% 50V
C3 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C4 1-116-385-81 CERAMIC CHIP 4.7PF 0.1PF 50V
C5 1-116-194-81 CERAMIC CHIP 33PF 1% 50V
C6 1-164-844-11 CERAMIC CHIP 4PF 0.25PF 50V
C8 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C10 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C11 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C12 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C13 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C15 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
* C16 1-118-401-11 CERAMIC CHIP 0.0015uF 10% 50V
C20 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C21 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C24 1-164-862-81 CERAMIC CHIP 33PF 5% 50V
C25 1-164-862-81 CERAMIC CHIP 33PF 5% 50V
* C28 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C30 1-116-722-11 CERAMIC CHIP 4.7uF 10% 16V
C100 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C101 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
* C102 1-116-727-11 CERAMIC CHIP 2.2uF 10% 16V
C103 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
(A415BT)
C104 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
(A415BT)
C105 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C200 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C202 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
C204 1-116-742-11 CERAMIC CHIP 0.22uF 10% 25V
C206 1-116-742-11 CERAMIC CHIP 0.22uF 10% 25V
C208 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
C209 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
C211 1-117-681-11 ELECT CHIP 100uF 20% 16V
C251 1-100-767-21 ELECT CHIP 220uF 20% 16V
* C253 1-120-086-11 ELECT CHIP 560uF 20% 25V
C300 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C301 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C302 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C303 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C304 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C305 1-116-733-11 CERAMIC CHIP 1uF 10% 25V
C306 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C307 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
* C308 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
C309 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
* C310 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
C311 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
* C312 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
C313 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
* C314 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
C315 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C316 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C317 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C318 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C319 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C320 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C321 1-116-733-11 CERAMIC CHIP 1uF 10% 25V
C322 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C323 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C324 1-116-733-11 CERAMIC CHIP 1uF 10% 25V
C325 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C326 1-116-733-11 CERAMIC CHIP 1uF 10% 25V
* C332 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C350 1-118-997-11 ELECT 3300uF 20% 16V
C400 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C401 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C402 1-116-722-11 CERAMIC CHIP 4.7uF 10% 16V
C404 1-164-315-91 CERAMIC CHIP 470PF 5% 50V
C406 1-164-315-91 CERAMIC CHIP 470PF 5% 50V
C407 1-116-722-11 CERAMIC CHIP 4.7uF 10% 16V
C409 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C410 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C411 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
(A415BT)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
Note 1: When the complete MAIN board is replaced, be sure to replace the knob
(VOL) assy (Ref. No NFC1) simultaneously. Also be sure to refer to
“NOTE OF REPLACING THE MAIN BOARD” on page 3.
Note 2: ANT001 on the MAIN board cannot replace with single.
When this part is damaged, replace the complete mounted
board.
KEY MAIN
Ver. 1.1
