38
Command List
Command List (4/6)
Command Set Command Command Packet Comments
CAM_AutoICR
On 8x 01 04 51 02 FF Auto dark-field mode On/Off
Off 8x 01 04 51 03 FF
Threshold 8x 01 04 21 00 00 0p 0q FF
pq: ICR ON
 OFF threshold level
CAM
_AutoICRAlarmReply
On 8x 01 04 31 02 FF Auto ICR switching Alarm ON/OFF
Off 8x 01 04 31 03 FF
(Reply) y0 07 04 31 02 FF
ICR OFF
 ON
y0 07 04 31 03 FF
ICR ON
 OFF
CAM_Memory Reset 8x 01 04 3F 00 0p FF p: Memory Number (=0 to 5)
Set 8x 01 04 3F 01 0p FF
Recall 8x 01 04 3F 02 0p FF
CAM_Display On 8x 01 04 15 02 FF
(8x 01 06 06 02 FF)
Display ON/OFF
Off 8x 01 04 15 03 FF
(8x 01 06 06 03 FF)
On/Off 8x 01 04 15 10 FF
(8x 01 06 06 10 FF)
CAM_Title Title Set1 8x 01 04 73 00 mm nn pp qq 00
00 00 00 00 00 FF
L: Line Number, nn: H-Position
pp: Color, qq: Blink
Title Set2 8x 01 04 73 01 mm nn pp qq rr ss
tt uu vv ww FF
mnpqrstuvw: Display character setting
(1st to 10th character)
Title Set3 8x 01 04 73 02 mm nn pp qq rr ss
tt uu vv ww FF
mnpqrstuvw: Display character setting
(11th to 20th character)
Title Clear 8x 01 04 74 00 FF Clear title setting
On 8x 01 04 74 02 FF Title display ON/OFF
Off 8x 01 04 74 03 FF
CAM_MultiLineTitle Title Set1 8x 01 04 73 1L 00 nn pp
qq rr 00 00 00 00 00 FF
L: Line Number, nn: H-position
pp: Color, qq: Blink rr: Opening Title
Title Set2 8x 01 04 73 2L mm nn pp
qq rr ss tt uu vv ww FF
L: Line Number,
mnpqrstuvw: Setting of characters (1 to 10)
Title Set3 8x 01 04 73 3L mm nn pp
qq rr ss tt uu vv ww FF
L: Line Number,
mnpqrstuvw: Setting of characters (11 to 20)
Title Clear 8x 01 04 74 1p FF Title Setting clear (p: 0 to a, f= all lines)
On 8x 01 04 74 2p FF Title display On/Off (0 to a, f= all lines)
Off 8x 01 04 74 3p FF
CAM_Mute On 8x 01 04 75 02 FF Muting ON/OFF
Off 8x 01 04 75 03 FF
On/Off 8x 01 04 75 10 FF
